Controls and indicators

4
„ Front panel
1.
LED Indicators
RED
MAGENTA In USB mode
BLUE
WHITE
GREEN
ORANGE
2.
Wall bracket holes
3.
Remote Control Sensor
4.
Duct ports
5.
button
Switch the sound bar between
ON and STANDBY mode.
5 6
In Standby mode
In Bluetooth mode
In HDMI mode
In Audio In mode
In Optical In mode
2
1
HDMI (ARC) USB AUDIO
IN
7 8
6.
button
Select the input function.
7.
button
Press to activate the pairing
function in Bluetooth mode or
disconnect the existing paired
Bluetooth device.
8.
Play or pause in Bluetooth and
USB modes.
9.
Decrease or increase the volume
level.
E-4
3
OPTICAL
IN
9
button
buttons
4
