Control Panel - Vivax 50UHD122T2S2SM Instruction Manuals

VIVAX

Control Panel

Model 50"
Turn the TV on or enter into
/ Power
standby mode.
Volume decreasing. In the TV
VOL-
Menu system, it acts like the
left arrow key on the remote
control and can be used to
select Menu options.
Volume increasing. In the TV Menu system, it acts like the left
VOL +
arrow key on the remote control and can be used to select Menu
options.
Short press to achieve Channel decreasing. Long press to achive
MENU/CH▼
MENU function.
MENU: Displays the TV Main menu
CH▼: Scans down trough the channel list. In the TV Menu system,
it acts like the down arrow on the Remote control and can be used
to select menu options.
INPUT/CH▲ Short press to achieve Channel increasing. Long press to achive
INPUT (Source) list.
INPUT: Displays the Source List
CH▲: Scans up trough the channel list. In the TV Menu system, it
acts like the down arrow on the Remote control and can be used
to select menu options.
Model 55", 65"
Turn the TV on or enter into standby mode.
/ Power
Signal source selection button.
INPUT
Enter / Exit the main menu.
MENU
CH ▼ Channel
decrease the channel No. and select the
last option in the menu.
CH ▲ Channel increasing short cut key; increase
the channel No. and select the next option
in the menu.
Volume decreasing short cut key; enter into
VOL-
the next menu and adjust OSD options
(decreasing).
Volume increasing short cut key; enter into
VOL +
the
options(increasing).
decreasing
next menu and
short cut key;
adjust OSD
14
ENG
Bottom part
