LINET CliniCare 100 HF Service Manual

Mattress replacement system
Hide thumbs Also See for CliniCare 100 HF:
Table of Contents

Advertisement

Quick Links

Download this manual
n7
SERVICE MANUAL
CliniCare 100 HF
Mattress Replacement System
D9S003VC0-0101
Date
8-2016
Version
01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CliniCare 100 HF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LINET CliniCare 100 HF

Summary of Contents for LINET CliniCare 100 HF

  • Page 1 SERVICE MANUAL CliniCare 100 HF Mattress Replacement System D9S003VC0-0101 Date 8-2016 Version...
  • Page 2 Czech Republic Tel.: +420 312 576 111 Fax: +420 312 522 668 E-mail: info@linet.cz http://www.linet.cz Service Manual CliniCare 100 HF - Mattress Replacement System Author: LINET, s. r. o. Related links: www.linet.com Version: 01 Print date: 8-2016 Copyright © LINET, s. r. o., 2016 Translation ©...

  • Page 3: Table Of Contents

    6.3.1 APT Mode (CliniCare 100 HF) .....................13 6.3.2 STATIC Mode (CliniCare 100 HF) ....................13 6.3.3 MCM Mode (CliniCare 100 HF with MCM) ..................13 6.3.4 APT + MCM Mode (CliniCare 100 HF with MCM) ...............13 7 Service Procedure ......................14 7.1 Annual Schedule ..........................14 7.2 Electrical Testing ..........................14...

  • Page 4: Introduction - General Information

    Mattress System meets the parameters that guarantee high quality, reliability and constant value. Linet are dedicated to serving your needs and providing the best products available along with training that will bring your staff maximum benefit from our products.

  • Page 5: Tools And Test Equipment

    Screw drivers (10mm, 15mm & 20mm Torx) (PZ 1 & 2) Recommended Service Spares Item Description Quantity SCU Filter Pack Mattress Cover Top Mattress Cover Bottom Tubing Service Kit Strapping Service Kit Fastening Service Kit SERVICE MANUAL – CliniCare 100 HF 5/30 Project Date 8-2016 Version...

  • Page 6: Introduction

    Do not use your Mattress System SCU in the presence of flammable gases. This excludes oxygen cylinders. CliniCare 100 HF is designed for use in all health care facilities, hospitals, nursing homes and community care as an aid to the prevention and treatment of skin injuries related to pressure damage.

  • Page 7: Safety Instructions

    Do not attempt to service CliniCare 100 HF system unless you have received full service training and documentation from Linet. NOTE: More concrete safety instructions for use can be found in the user manual for CliniCare 100 HF. Risk Assessment ...

  • Page 8: Symbols And Labels On The Product

    Disinfect using solution containing <1000 ppm of Chlorine (see Cleaning/Disinfection). Rinse with water. Dry. Cover Materials are Fire Retardent to BS7175, Sources 0, 1 and 5. Regulary inspect the inside of the cover for contamination. SERVICE MANUAL – CliniCare 100 HF 8/30 Project Date 8-2016 Version...

  • Page 9: Control Panel Description

    Static mode provides a stable surface for the patient when getting into or out of bed or if required when performing nursing procedures. Air cell pressure can be varied using the manual pressure control. When STATIC mode is selected:  SCU will inflate all cells to the same pressure. SERVICE MANUAL – CliniCare 100 HF 9/30 Project Date 8-2016...

  • Page 10: Clinicare 100 Hf With Mcm

    5.2.2 APT + MCM – Alternating pressure therapy and MCM mode CliniCare 100 HF operates by alternating pressure in a 2 cell system in a 12 minute interval cycle, which imitates the natural movement of the patient. The version of the mattress with MCM Mode includes MicroClimate Management.

  • Page 11: System Performance Test

    System Connection Ensure that the test adaptor (2) is fitted with the correct connector block for the CliniCare 100 HF (D7000662 which is part of S7000184E). Insert the Air Connector (1) into the Test Adaptor (2) and insert the Air Connector/Test Adaptor into the SCU as shown in figure 03.

  • Page 12: Scu Power On Test

    SCU Power on Test Switch on the SCU using the power ON /OFF switch on the front of the SCU (CliniCare 100 HF see figure 1, CliniCare 100 HF with MCM see figure 2) and select Static mode (CliniCare 100 HF) or MCM mode (CliniCare 100 HF with MCM).

  • Page 13: Pressure Tests

    6.3.1 APT Mode (CliniCare 100 HF) Set the Mode to APT using the Mode selection switch on CliniCare 100 HF. Set the Pressure control dial to its 'LOW' position. Using the Sphygmomanometer test gauges ensure that each cell achieves a...

  • Page 14: Service Procedure

    Servicing should only be performed by qualified Linet personnel unless you have received formal Linet training beforehand. Only personnel trained or formally approved by Linet in the operation and maintenance of your Mattress System may perform maintenance, modification or repair work. Unqualified personnel attempting to work on Linet products risk serious injury to themselves / others and possibly death by electrocution.

  • Page 15: Scu Servicing (External)

    Using an Electrical Safety Tester ensure the SCU passes the 500 Volt Insulation Test.  Wipe the SCU over with a disinfectant cloth ensuring all dirt and dust particles are removed. Fig. 05 CliniCare 100 HF Filter Position SERVICE MANUAL – CliniCare 100 HF 15/30 Project Date 8-2016...

  • Page 16: Scu Servicing (Internal)

    Visually inspect all of the pipes for signs of damage and internal dirt / dust. Replace if necessary.  (CliniCare 100 HF) Check Pressure Sensor pipe is in good condition as shown in figure 08. Fig. 07 Air Pipes Connection inside CliniCare100 HF SERVICE MANUAL –...

  • Page 17: Mattress Servicing (External)

    Visually inspect the 2 x 1 amp Ceramic Power Supply PCB fuses. Ensure they are rated at the correct value. See figure 09. Fig. 08 CliniCare 100 HF Fuses Placement inside CliniCare 100 HF SCU  Re-fit the rear cover and secure the rear cover with the 6 retaining screws.

  • Page 18: Routine Maintenance Visual Checks & Performance Tests Matrix

     Check air connector for mechanical damage & screw    fixings.  Check air connector block tightness and operation of    transport mode.  Check air connector indicator label.    SERVICE MANUAL – CliniCare 100 HF 18/30 Project Date 8-2016 Version...
  • Page 19     General Noise level when compressor running.     General Vibration level when compressor running.     Perform any outstanding field upgrades. SERVICE MANUAL – CliniCare 100 HF 19/30 Project Date 8-2016 Version...

  • Page 20: System Faults

    System faults are indicated by the amber light on the SCU. NOTE: During initial inflation the CliniCare 100 HF low pressure indication will come on until the mattress has achieved its minimum pressure. This does not a mean there is a fault unless it remains on for more than 30 minutes.

  • Page 21: Troubleshooting

    Open the mattress cover and check that no air pipes are damaged or disconnected NOTE: For Air 2 Care 10 only: Slightly increase the pressure setting and see if problem stops. Then ①. SERVICE MANUAL – CliniCare 100 HF 21/30 Project Date 8-2016 Version...
  • Page 22 NOTE: If any of the above problems occur and cannot be solved by the user it is recommended to put the mattress into Transport mode (see chapter „Transport mode“) to ensure that the patient is supported while waiting for a service engineer to arrive. SERVICE MANUAL – CliniCare 100 HF 22/30 Project...

  • Page 23: Fault Diagnosis Level 1

    10.1 Fault Diagnosis Level 1 SERVICE MANUAL – CliniCare 100 HF 23/30 Project Date 8-2016 Version...

  • Page 24: Schematic Drawing - Clinicare 100 Hf

    10.2 Schematic Drawing – CliniCare 100 HF SERVICE MANUAL – CliniCare 100 HF 24/30 Project Date 8-2016 Version...

  • Page 25: Schematic Drawing - Clinicare 100 Hf With Mcm

    10.3 Schematic Drawing – CliniCare 100 HF with MCM SERVICE MANUAL – CliniCare 100 HF 25/30 Project Date 8-2016 Version...

  • Page 26: Environmental Conditions

    Dust and water protection (SCU) IP 3X Flammability rating (mattress and cushion BS7175, ignition source 0, 1 & 5 covers) Enviroment ISO 14001 2011/65/EU (RoHS) 2002/96/EC (WEEE) Electromagnetic compatibility EN 60601-1-2 SERVICE MANUAL – CliniCare 100 HF 26/30 Project Date 8-2016 Version...

  • Page 27: Technical Specifications

    270 x 120 x 220 mm Weight  2,5 kg Cycle  Mattress (inflated) 2 cells, 12 minutes Maximal load (SWL) 230 kg Inflation time  APT mode 30 min Noise level 35 dBA SERVICE MANUAL – CliniCare 100 HF 27/30 Project Date 8-2016 Version...

  • Page 28: Operating Pressure Settings

    15VA Fuse 2x T 1A L anti-surge fuse (250 V, type 5x20mm) Electrical safety class Class II with applied parts type B Electrical safety In conformity with EN 60601-1 SERVICE MANUAL – CliniCare 100 HF 28/30 Project Date 8-2016 Version...

  • Page 29: Disposal

    Materials of the appliance may be reused. When recycling or reusing old appliances you are making an important contribution in the protection of the environment.  Ask the responsible environmental protection authorities for the appropriate disposal point.  Observe local and country-specific specifications for disposal. SERVICE MANUAL – CliniCare 100 HF 29/30 Project Date 8-2016 Version...

  • Page 30: Warranty And Service

    14 Warranty and Service LINET® will only be held responsible for the safety and reliability of products that are regularly serviced and used in accordance with the safety guidelines. Should a serious defect arise that cannot be repaired during maintenance: ...
