Device Description; Delivery Set; Filling The Water Tank - Timberk Harmony Series Instruction Manual

IM2020
5.

DEVICE DESCRIPTION

6.

DELIVERY SET

1. Ultrasonic humidifier - 1 pc.
2. Brush – 1 pc.
3. Instruction manual – 1 pc.
4. Warranty card - 1 pc.
5. Packaging - 1 pc.
7.

FILLING THE WATER TANK

1. Place the device on flat and dry surface. Unplug the device (fig. 2)
2. Remove the water filling cap and pour the water inside the water tank (fig. 3)
3. Don't pour the water above max water level which is indicated on the mist outlet tube inside the water tank
(distance between water and mist outlet should be at least 10mm) (fig. 4)
Rated current
Noise level
Moisture protection
class
Electrical protection
class
Device dimensions
Net weight
А
dB(А)
-
-
mm
kg
Fig. 1*
*The appearance of the device may differ from the images in
the manual
1. Water filling cap
2. Tank cover
3. Filler
4. Spray nozzle
5. Aroma box
6. Tank
7. Float rod
8. Display screen
13
0.224
≤ 35
IPX0
Class II
215x146x275
1.17
