2.1 - Powering the Extractor

Plug the power cord from the extractor into a standard
grounded wall outlet. The extractor operates off a single,
♦
grounded 20 amp outlet.

2.2 - Filling the Solution Tank

Lift the tank lid and, using a bucket, fill the solution tank via the
large opening. For best results, use warm water.

2.3 - Connecting the Hoses

Do not operate machine with a spray nozzle
orifice smaller than #2. This can damage the pump
switch.
Do not pull on hoses in order to move the unit. Use
only the appropriate handles.
Connect the vacuum hose to
the Cuff-Lynx hose connec-
tion on the vacuum tank. Twist
clockwise to lock into place.
Connect the solution hose to
the brass quick connect fitting
on the base of the machine. To
connect, pull back the flange
on the female fitting from the hose and slide onto the male
fitting on the machine. Release to lock fittings together.

2.4 - Operating the Extractor

In order to avoid vapor locking the unit, the components
should be switched on by following the procedure below after a
cleaning tool is connected:
1. Turn pump switch on. Pull the lever on the cleaning tool to
release air in the line. Hold lever until a steady flow of water
comes out of the tool.
♦
2. Once pump is primed and there is pressure in the solution
line, turn on heater switch and wait a few minutes for water to
heat up.
3. Once water is heated, turn on vacuum and begin cleaning.
Cleaning Procedure
For best results when extracting, do one wet pass followed
by two dry passes. This ensures you're not over-soaking the
material and keeps water temperature higher.
The solution pump will only turn on when there is a pressure
♦
demand (e.g., while spraying with cleaning tool, or right at
startup). If the pump is continuously running or pulsing, it
does not necessarily mean that it is defective. If the pump
is not producing the correct pressure and flow, see the
Troubleshooting section of this manual.
9

2 - Machine Operation

3 1 2
Use only low foam or non foaming detergent or
shampoo. Damage due to excessive foam will void
warranty.
Empty the vacuum tank any time you refill the
solution tank in order to prevent vacuum tank
overfilling.
♦
