Summary of Contents for Mytee 2002CS
- Page 1 User Manual Model: Contractor’s Special 2002CS REV. 7/26/21 Carpet Cleaning Package 13655 Stowe Dr. Poway, CA 92064 P: (858) 679-1191 F: (858) 726-6005 www.mytee.com...
- Page 2 Congratulations on the purchase of your new Contractor’s Special Carpet Extractor Package. As technology continues to develop you can work confidently knowing that both Mytee and its employees are equally dedicated to developing with the industry and its advances. Like any other piece of machinery or technology, the Contractor’s Special also requires proper maintenance and care to keep the product working over extended use.
-
Page 3: Table Of Contents
Table of Contents Important Safety Information At a Glance 1.1 - Technical Specifications 1.2 - Included in the Contractor’s Special Package 1.3 - Extractor Front View 1.4 - Extractor Rear View Machine Operation 2.1 - Powering the Extractor 2.2 - Filling the Solution Tank 2.3 - Connecting the Hoses 2.4 - Operating the Extractor 2.5 - Emptying the Tanks... -
Page 4: Important Safety Information
When and if calling This machine must be grounded. If it should malfunction or break Mytee for support, please have your Model and Serial Number down, grounding provides a path of least resistance for electrical available for faster assistance. - Page 5 Important Safety Information To reduce the risk of fire, electrical shock, or injury: may contain: chemicals, grease, oil, acid, alkalines, or other dangerous liquids. 1. Read all instructions before using equipment. 19. Do not leave operating unattended. 2. Use only as described in this manual. Use only manufacturer’s recommended attachments.
-
Page 6: At A Glance
1 - At a Glance 1.1 - Technical Specifications Solution Tank 10 gallon capacity Recovery Tank 9 gallon capacity Single 3-stage low amp Vacuum Motor 100 CFM, 130” water lift 120 PSI diaphragm pump Pump 1.3 GPM 1,200W REAL HEAT™ system Heater 210º... -
Page 7: Extractor Front View
1 - At a Glance 1.3 - Extractor Front View 1. Clear recovery tank lid 6. Rear foam-filled wheels 2. Switch plate 7. Solution line quick connect 3. Solution tank lid 8. Vacuum hose Cuff-Lynx™ connection 4. Solution tank 9. Recovery tank 5. -
Page 8: Extractor Rear View
1 - At a Glance 1.4 - Extractor Rear View 1. Rear recovery tank drain valve 3. Power cord 2. Rear body bracket screws... -
Page 9: Machine Operation
2 - Machine Operation 2.1 - Powering the Extractor 2.4 - Operating the Extractor Plug the power cord from the extractor into a standard grounded wall outlet. The extractor operates off a single, ♦ grounded 20 amp outlet. 2.2 - Filling the Solution Tank In order to avoid vapor locking the unit, the components should be switched on by following the procedure below after a cleaning tool is connected:... -
Page 10: Emptying The Tanks
2 - Machine Operation 2.5 - Emptying the Tanks Empty the recovery tank via the drain valve on the rear of the machine. Make sure there is a bucket in place under the valve or the machine is in a position so the dirty water is drained safely. -
Page 11: Machine Maintenance
In order to keep the extractor running smoothly and reduce the 2. Connect a cleaning tool (upholstery tool, wand, etc.) and risk of damage to the machine and subsequent downtime, Mytee remove the jet(s) in order to prevent clogging from dislodged recommends following the maintenance schedule below: mineral build-up. -
Page 12: Troubleshooting
Circuit breaker tripped in building. Reset breaker in building. turning on. Faulty switch or power cord. Contact a Mytee Service Center. Unclog the jet by removing and soaking in a vinegar Jet is clogged. and water solution. Scrub with a soft brush. Repeat if Poor solution flow. - Page 13 NOTES...
- Page 14 Mytee, LLC 13655 Stowe Dr. Poway, CA 92064 www.mytee.com © 2021 Mytee, LLC...
