Parameter
Power supply
Display
Active area of
display, W × H
Pixel errors
Backlight brightness
Backlight lifetime
Operating
temperature
Storage temperature
Relative humidity in
operation
Vibration
Mechanical shock
UL approval
Beijer Electronics, MAEN330
X2 base 7 v2 HP
+24 VDC (18-32 V DC)
CE: The power supply must conform with the requirements
according to EN/IEC 60950 and EN/IEC 61558-2-4.
UL and cUL: The power supply must conform with the
requirements for class 2 power supplies.
7.0" TFT-LCD with LED backlight. 800x480 pixels, 16M
colors
154.08 x 85.92
Class I (ISO 9241-307)
400 cd/m2
20000 hours
0 °C – +50 °C
-20 °C – +60 °C
5 - 90% non-condensed /25°C
1g, according to IEC 60068-2-6, Test Fc
10g, half-sine, 6ms according to IEC60068-2-27
Information is available on
ics.com
and/or
https://UL.com
Technical Data
http://www.beijerelectron-
12
