Beijer Electronics X2 control Startup Manual

X2 control – Start Up guide Basic settings

1 Introduction

This document goes through the basic settings and describes the required function and areas
required to use the the X2 control device using the CODESYS and iX Developer program to
achieve an easily get started.
With the HMI soft controllers in the X2 control series, any HMI application can have an
intuitive graphic iX interface with total CODESYS control.
The CODESYS SoftController can communicate with external devices, for example Remote
I/O. The different communication types are explained in detail in separate documents, see
chapter 4.

2 Precautions

This Start Up document should not be considered as a complete manual. It´s aimed to get the
user a guidline for an easy and quick setup of the configuration.
Copyright © Beijer Electronics, 2017
This documentation (below referred to as 'the material') is the property of Beijer Electronics. The holder or
user has a non-exclusive right to use the material.
The holder is not allowed to distribute the material to anyone outside his/her organization except in cases
where the material is part of a system that is supplied by the holder to his/her customer.
The material may only be used with products or software supplied by Beijer Electronics.
Beijer Electronics assumes no responsibility for any defects in the material, or for any consequences that
might arise from the use of the material.
It is the responsibility of the holder to ensure that any systems, for whatever applications, which is based on
or includes the material (whether in its entirety or in parts), meets the expected properties or functional
requirements.
Beijer Electronics has no obligation to supply the holder with updated versions.
All safety and accident prevention regulations relevant to your specific application must be observed in the
system design, installation, configuration, maintenance, servicing and testing of this product.
When making programs for this product make sure to leave sufficient CPU power for the HMI-part of the
product to be able to execute smoothly.
It´s recommended to keep the CPU-load below 80% on the kernel that CODESYS control applications run on.
See chapter 13, to monitor the CPU-load.
