Image Manual X2 base v2
English
MAEN352, 2021-01

Advertisement

Table of Contents
loading

Related Manuals for Beijer Electronics Image Manual X2 base v2

Summary of Contents for Beijer Electronics Image Manual X2 base v2

  • Page 1 Image Manual X2 base v2 English MAEN352, 2021-01...
  • Page 2 Beijer Electronics AB assumes no responsibility for any errors that may appear in this document. All examples in this document are only intended to improve understanding of the functionality and handling of the equipment. Beijer Electronics AB cannot assume any liability if these examples are used in real applications.

  • Page 3: Table Of Contents

    Image + New iX Developer Project ......15 Updating the Panel Image over Ethernet ....... 15 iX Developer Project Status after Panel Image Update ..18 5 Creating a custom Welcome Screen ........19 Beijer Electronics, MAEN352...

  • Page 4: Introduction

    Microsoft, Windows, Windows embedded CE6, Windows Embedded Compact 2013, Windows 7, Windows Embedded Standard 7 are registered trademarks or trademarks of Microsoft Corporation in the USA and/or other countries. Any additional trade names given in this documentation are trademarks of their corresponding owners. Beijer Electronics, MAEN352...

  • Page 5: References

    The installation, technical data as well cutout and outline dimensions of the panels are described in the installation manual for each operator panel. Please refer to the Installation manuals and the iX Developer manual for further information. Note: Current documentation and software updates can be found on http://www.beijerelectronics.com Beijer Electronics, MAEN352...

  • Page 6: Operating Systems

    Introduction Operating Systems Runtime Versions Panel family Description (licenses) X2 base v2 Windows Embedded Includes support of most existing Compact 2013 features. X2 base v2 HP Runtime (General embedded) Beijer Electronics, MAEN352...

  • Page 7: Boot

    IP-settings should be restored. Position Description Panel type. Network status. An attached network cable is indicated with an asterisk. Panel image main version and build number. Beijer Electronics, MAEN352...

  • Page 8: Service Menu

    The following parameters can be set: • IP address • Subnet mask • Default gateway • DNS settings for the Ethernet port on the operator panel The default setting for LAN A is: IP address 192.168.1.1, Subnet mask 255.255.255.0 Beijer Electronics, MAEN352...

  • Page 9: Date / Time

    USB flash drive or storage device connected to one of the operator panels USB-ports. 3.5.2 Copy Project to SD Card This option enables the function to copy the iX Developer project and all the files needed to run the application to an external SD Card. Beijer Electronics, MAEN352...

  • Page 10: Copy Project To Usb

    Self Test The self test screen looks a little different depending on operator panel type. To be able to fully test the Carrier unit, a complete set of test plugs, SD-card and a USB flash drive is needed. Beijer Electronics, MAEN352...

  • Page 11: Touch Calibrate

    The operator panel stops storing debug log data. The data will remain in the operator panel internal memory. Move Log to USB Memory Moves the debug log files in the operator panel to an external USB storage device. Beijer Electronics, MAEN352...

  • Page 12: Diagnostic

    Shows the make, model and revision of the operator panel. System Board Shows hardware information of the System board in the operator panel. Display Card Shows hardware information of the Display card in the operator panel. Selftest Shows the result of the last selftest. Beijer Electronics, MAEN352...

  • Page 13: Export Diagnostic Information

    Export Diagnostic Information Click Save to USB memory to export the diagnostic information to an external USB flash drive or other USB connected storage device. Make sure that the storage device is connected before trying this option. Beijer Electronics, MAEN352...

  • Page 14: Image Update

    Using a USB flash drive or SD-card to update the image in an operator panel is the preferred method of updating the panel. This makes it possible to upgrade the panel image without the use of a PC. Beijer Electronics, MAEN352...

  • Page 15: Image + New Ix Developer Project

    192.168.1.2 – 192.168.1.254 and a netmask of 255.255.255.0, in order to be able to communicate with the panel. To enter the update mode on a iX TxA or X2 base, press a finger on the screen and apply power to the panel. Beijer Electronics, MAEN352...
  • Page 16 2. Make sure that the IP address of the panel matches the actual panel that you want to upgrade. 3. The dialog shows the current installed image and the new image the panel will be updated to after the upgrade. Click on Update now! to confirm the update. Beijer Electronics, MAEN352...
  • Page 17 Image Update 4. The progress bar shows the upgrade status. When the upgrade is done, the panel will restart. Beijer Electronics, MAEN352...

  • Page 18: Developer Project Status After Panel Image Update

    If the panel image upgrade is made over Ethernet, an additional dialog will pop up to confirm an erasing of the current iX Developer project. The default setting is not to erase the iX Developer project. Beijer Electronics, MAEN352...

  • Page 19: Creating A Custom Welcome Screen

    5. Reboot the panel to load the new Welcome Screen. Tip: To check the panel resolution, start iX Developer, and in the wizard select the correct panel type, and then check the technical data displayed for the operator panel. Beijer Electronics, MAEN352...
  • Page 20 Head office Beijer Electronics AB Box 426 201 24 Malmö, Sweden www.beijerelectronics.com / +46 40 358600...
