- Page 1 X2 base 5 v2 English MAEN328, 2021-05...
- Page 2 The information in this document is subject to change without notice and is provided as available at the time of printing. Beijer Electronics AB, including all its group companies, reserves the right to change any information without updating this publication. Beijer Electronics AB, including all its group companies, assumes no responsibility for any errors that may appear in this document.
-
Page 3: Table Of Contents
Touch Screen Protector ......... . 14 6 Operator Panel Drawings ..........15 Connectors ............15 X2 base 5 v2 Outline ..........17 7 Additional Installation Tips ..........18 Grounding the operator panel ........18 Ethernet Connection in the Operator Panel .... -
Page 4: Safety Precautions
Safety Precautions Safety Precautions Both the installer and the owner and/or operator of the operator panel must read and understand this installation manual. 1. 1 General • Read the safety precautions carefully. • Check the delivery for transportation damage. If damage is found, notify the supplier as soon as possible. -
Page 5: Disposal Requirementsunder Weee Regulations
Safety Precautions 1. 3 Disposal RequirementsUnder WEEE Regulations For professional users in the European Union: If you wish to discard electrical and electronic equipment (EEE), please contact your dealer or supplier for further information. For disposal in countries outside of the European Union: If you wish to discard this product please contact your local authorities or dealer and ask for the correct method of disposal. -
Page 6: Dismantlingand Scrapping
Safety Precautions 1. Apply cleaning agent (alcohol, bleach, or glass cleaner) to a clean cloth. Make sure the cloth is well saturated. 2. Wipe touch panel in a “Z” motion on the touch panel surface. 3. Dry the panel thoroughly with a dry cloth, removing as much of the cleaning solution as possible. -
Page 7: Namingconvention
(= wit h Sealed Rugged Only ext reme fi Cert i cat ion Only Examples: • X2 base 5 v2 • X2 pro 7 • X2 control 10 • X2 marine 12 SC • X2 marine 15 HB SC •... -
Page 8: Installation
2. To cut a correct opening for the operator panel, use the cut out dimensions in the outline drawing.A separate cut out drawing is available for download from the Beijer Electronics web site. For more information, see sections Operator Panel Drawings Technical Data. - Page 9 Installation 3. Make sure that the mounting surface of the cutout is smooth and cleaned from any burrs or debris. 4. Install the operator panel into the cutout. 5. In cases where the front panel seal is critical, use a torque wrench to ensure all screws are torqued within the specification above.
-
Page 10: Connectionsto The Controller
Installation 3. 2. 1 Connectionsto the Controller For information about the cables to be used when connecting the operator panel to the controller, please refer to the help file for the driver in question. 3. 2. 2 Other Connectionsand Peripherals Cables, peripheral equipment and accessories must be suitable for the application and its environment. -
Page 11: Technical Data
Technical Data Technical Data Parameter X2 base 5 v2 Front panel, W × H × D 172x109x37 mm Cut out dimensions, 161x93 (+/ -1) mm W × H Mount ing dept h 32 mm (132 mm including clearance) Mount ing... - Page 12 Technical Data Parameter X2 base 5 v2 Power supply +24 VDC(18-32 V DC) CE: The power supply must conf orm wit h t he requirement s according t o EN/ IEC60950 and EN/ IEC61558-2-4. UL and cUL: The power supply must conf orm wit h t he requirement s f or class 2 power supplies.
-
Page 13: Chemical Resistance
Chemical Resistance Chemical Resistance 5. 1 Touch Screen and Overlay Material 5. 1. 1 Protective Film Solvent Resistance The protective film withstands exposure of more than 24 hours duration under DIN 42 115 Part 2 to the following chemicals without visible change: Acet onit rile Diesel Pet roleum spirit... -
Page 14: Touch Screen Surface
5. 1. 3 Touch Screen Protector For harsh environments and exposure to outdoor conditions, it is recommended to use a protective film to guard the touch screen from damage. This optional part can be ordered from Beijer Electronics. Beij er Electronics, MAEN328... -
Page 15: Operator Panel Drawings
Operator Panel Drawings Operator Panel Drawings 6. 1 Connectors Connect or Descript ion Ground screw Screw t o connect f unct ional grund Power supply 3-pin screw connect or, +24V DC(18-32V DC) COM-A DSUB (9-pin, f emale), serial communicat ion port LAN-A RJ 45 (shielded), 10/ 100Mbit USB-A... - Page 16 Operator Panel Drawings COM-C Serial port pin assignment COM6 RS485 Tx+/ Rx+ RS485 Tx-/ Rx- Beij er Electronics, MAEN328...
-
Page 17: X2 Base 5 V2 Outline
Operator Panel Drawings 6. 2 X2 base 5 v2 Outline X2 base 5 v2 Note: Minimum t hicknessf or t he f ront plat e is 2. 0 mm. Note: fi www.beij erel ect ronics.com A St ep CAD le is avail able on t he web sit e... -
Page 18: Additional Installation Tips
Additional Installation Tips Additional Installation Tips When experiencing communication problems in noisy environments or when operating close to temperature limits, the following recommendations are to be noticed. 7. 1 Groundingthe operator panel Mounting plate in the cabinet Door Operator panel Power supply 24 V DC Ferrite core... -
Page 19: Ethernet Connection In The Operator Panel
Additional Installation Tips Note: The grounding wiresshould be short and t he conduct or should have a large area. A long, t hin grounding wire hasa very high impedance (resist ance) at high f requencies and doesnot guide dist urbancest o t he ground. Mult i-wire conduct ors are bet t er t han single wire conduct orswit h t he same area. -
Page 20: To Achieve Better Emcprotection
7. 3 To Achieve Better EMCProtection • Initially, use the original cabling from Beijer Electronics primarily. • Place the 24 V DC and communications cabling in one cable trunk/cable duct and 230/380 V AC in another. If the cables need to be crossed, cross them at 90°... -
Page 21: Ambient Temperature
Additional Installation Tips Metal cabinet Metal cabinet Terminal or connector Terminal or connector Cable clamp in steel EMC cable gland Plastic cable gland Shielded cable Shielded cable 1. Use an EMC cable gland or regular plastic cable gland, remove the outer jacket and connect the shield to the installation plate with a 360°... - Page 22 Additional Installation Tips increase that would be expected. All electronics are sensitive to heat. The lifespan of an electrolytic capacitor is cut in half with an 8-10 °C increase in temperature. A 15-20 °C temperature increase results in a quarter of the lifespan etc. Rittal has a good program for estimating the anticipated average temperature in the cabinet as well as a large program for controlling the temperature in the device cabinet.
-
Page 23: Safety
Additional Installation Tips 7. 5 Safety Power supply 230 V AC to 24 V DC Operator panel +24 V Power supply 230 V AC to 24 V DC Operator panel +24 V Distance? Power supply 230 V AC to 24 V DC Operator panel +24 V Small controller with expansion unit... -
Page 24: Galvanic Isolation
Additional Installation Tips 7. 6 Galvanic Isolation Internal electronics Ethernet DC/DC galvanic isolation Filter DC/AC +24 V DC 0 V (GND) 1.5 m RS422/485 RS232 The operator panel has galvanic isolation against the 24 V DC power supply but no galvanic isolation between the communication ports for RS-232, RS-422/RS-485 and USB. - Page 25 Additional Installation Tips Operator panel Modular controller Printer Power CPU COM COM2 RS422 RS232 Different ground potential = Internal 0 V (GND) connection When a PC is connected to the operator panel, the internal 0 V (GND) of the panel is connected to the protective ground via the PC. A number of USB devices can have the shield connected together with the protective ground.
-
Page 26: Cable And Bustermination Rs-485
Additional Installation Tips 7. 7 Cable and BusTermination RS-485 • If maximum transfer distance and maximum transfer speed is needed, shielded and twisted pair cable should be used. The mutual capacitance may not exceed 52.5 pF/m, and the cable area should be at least 0.25 mm (AWG 24). - Page 27 fi Head of Beij er Elect ronicsAB Box 426 201 24 Malmö, Sweden www. beij erelect ronics. com / +46 40 358600...
