Beijer Electronics X2 extreme 7 Manual
Hide thumbs
Also See for X2 extreme 7:
- Quick start manual (61 pages) ,
- Installation manual (30 pages) ,
- Hardware and installation manual (30 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Beijer Electronics X2 extreme 7
Summary of Contents for Beijer Electronics X2 extreme 7
- Page 1 X2 extreme 7 English MAEN249B, 2021-11...
- Page 2 The information in this document is subject to change without notice and is provided as available at the time of printing. Beijer Electronics AB, including all its group companies, reserves the right to change any information without updating this publication. Beijer Electronics AB, including all its group companies, assumes no responsibility for any errors that may appear in this document.
-
Page 3: Table Of Contents
Communication Ports ......... . .20 X2 extreme 7 Outline ..........21 7 Additional Installation Tips .......... -
Page 4: Safety Precautions
有毒 和有 害的 材料 或元 素 Cr6+ PBDE PCB and electronic components PCB 和电子元件 O: Indicates that this toxic or hazardous substance contained in all of the homogenous materials for this part is below the limit requirement in SJ/T 11363–2014. Beijer Electronics, MAEN249B... -
Page 5: Disposal Requirements Under Weee Regulations
CE PRODUIT CONTIENT UNE PILE QUI NE PEUT PAS ÊTRE REMPLACÉE PAR L'UTILISATEUR. Warning: Potential electrostatic charging hazard, see instrucions. To avoid electrostatic charge build-up, it must not be rubbed or cleaned with solvents or a dry cloth when installed/used within a potentially explosive atmosphere. Beijer Electronics, MAEN249B... -
Page 6: Iecex/Atex Certificate And Dust Rating
CHAîNE DE PROTECTION Ex ec nC IIC T4 Gc et Ex tc IIIC T82 °C Dc. IECEx/ATEX Certificate and Dust Rating II 3 G Ex ec nC IIC T4 Gc II 3 D Ex tc IIIC T82 °C Dc Beijer Electronics, MAEN249B... -
Page 7: Conditions Of Safe Use For Zone 2/22 Atex/Iecex
Before carrying out any cleaning or maintenance operations, disconnect the equipment from the electrical supply. • Clean the display and surrounding front cover with a soft cloth and mild detergent. • The battery must be replaced by an authorized Beijer Electronics service center. Beijer Electronics, MAEN249B... -
Page 8: Cleaning The Display
• Ensure moisture does not seep through the cable connection area from the edges during cleaning. 1.10 Dismantling and Scrapping • The operator panel or parts thereof shall be recycled according to local regulations. Beijer Electronics, MAEN249B... -
Page 9: 1.11 Appearance Of Air In Touch Screen
The layer structure of the touch screen contains air. In rare cases, the appearance of bubbles can arise. This is purely cosmetic and does not affect the functionality of the operator panel. The appearance can occur under certain environmental conditions such as temperature, humidity, and atmospheric pressure. Beijer Electronics, MAEN249B... -
Page 10: Naming Convention
X2 marine 15 HB SC • X2 extreme 7 12V* • X2 extreme 12 HP SC* • X2 extreme 7 SL HP* • X2 extreme 12 SL HP SC* • X2 extreme 7 CO* • X2 extreme 12 SL HP RO Note: Not all combinations are available. -
Page 11: Installation
2. To cut a correct opening for the operator panel, use the cut out dimensions in the outline drawing. A separate cut out drawing is available for download from the Beijer Electronics web site. For more information, see sections Operator Panel Drawings Technical Data. - Page 12 flatness < 1 mm overall and < 0.05 mm/mm with a surface roughness, Ra < 1.6 μm 7. Installation to be through an EPL (Db)(Dc) enclosure for the applicable Dust Group, Temperature classification and Ambient temperature range. Beijer Electronics, MAEN249B...
-
Page 13: Connections To The Controller
3.2.1 Connections to the Controller For information about the cables to be used when connecting the operator panel to the controller, please refer to the help file for the driver in question. Beijer Electronics, MAEN249B... -
Page 14: Hazardous Location Installation
Connect the desired cables and attach them to strain relief plate with cable ties provided. 3.2.3 Other Connections and Peripherals Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier. Beijer Electronics, MAEN249B... -
Page 15: Technical Data
Technical Data Technical Data Parameter X2 extreme 7 Front panel, W × H × D 205 × 143 × 7 mm Cut out dimensions, 188±1 mm × 127±1 mm W × H Maximum corner radius: 4 mm. 394 x 270 mm. -
Page 16: Compass Safe Distance
Technical Data Parameter X2 extreme 7 Power supply +24 V DC (18–32 V DC) CE: The power supply must conform with the requirements according to EN/IEC 60950 and EN/IEC 61558-2-4. UL and cUL: The power supply must conform with the requirements for class 2 power supplies. -
Page 17: Chemical Resistance
Phenol Xylene Ammonia, conc. Sodium hydroxide 5% 97 octane unleaded petrol Ethyl acetate Sodium hydroxide 30% 98 octane leaded petrol Touch Screen and Overlay Material 5.2.1 Protective Film Autoflex EBA 180L covers the overlay surrounding the screen. Beijer Electronics, MAEN249B... - Page 18 The Autoflex protective film is not resistant to high pressure steam at over 100 °C or the following chemicals: Concentrated mineral acids Benzyl alcohol Concentrated caustic solution Methylene chloride Beijer Electronics, MAEN249B...
-
Page 19: Touch Screen Surface
5.2.3 Touch Screen Protector For harsh environments and exposure to outdoor conditions, it is recommended to use a protective film to guard the touch screen from damage. This optional part can be ordered from Beijer Electronics. Beijer Electronics, MAEN249B... -
Page 20: Operator Panel Drawings
RS-422 Tx- CAN 1-L RS-485 Tx-/Rx- RS-232 RTS RS-232 CTS RS-485 RS-422 Rx- CAN 2-L Tx-/Rx- The connector supports up to three independent communication channels and can be configured for RS-232 and RS-422 or 2xRS-485 or 2x CAN. Beijer Electronics, MAEN249B... -
Page 21: X2 Extreme 7 Outline
Operator Panel Drawings X2 extreme 7 Outline Beijer Electronics, MAEN249B... - Page 22 Operator Panel Drawings Note: A Step CAD file is available on the web site www.beijerelectronics.com Beijer Electronics, MAEN249B...
-
Page 23: Additional Installation Tips
3 turns around the ferrite core provide 9 times the suppression of 1 turn. Connect a wire or grounding braid, that is sized correctly according to local electrical codes, between the chassis of the operator panel and the closest grounding point. Beijer Electronics, MAEN249B... -
Page 24: Ethernet Connection In The Operator Panel
1. Check whether the other Ethernet unit has its shield directly grounded or grounded via a capacitor. Note: In many cases, connecting the shielded Ethernet cabling to the chassis at both ends is inappropriate. Hum or grounding loops can occur. Unshielded cabling may even result in fewer communication errors. Beijer Electronics, MAEN249B... -
Page 25: To Achieve Better Emc Protection
This connects the HF transients to ground. To Achieve Better EMC Protection • Initially, use the original cabling from Beijer Electronics primarily. • Place the 24 V DC and communications cabling in one cable trunk/cable duct and 230/380 V AC in another. If the cables need to be crossed, cross them at 90°... -
Page 26: Ambient Temperature
Install the fan so that it sits in a cooler area and blows cold air against the operator panel. If the fan is mounted at the top and sucks warm air upwards, the ambient temperature of the fan becomes higher, resulting in a shorter lifespan. Beijer Electronics, MAEN249B... - Page 27 This is assuming that all supplied power is transformed to heat. Note: Please ensure that the temperature will not exceed the maximum ambient operating temperature in the enclosure. This can be influenced by other heat generating devices. Beijer Electronics, MAEN249B...
-
Page 28: Safety
Transients on the 24 V feed are connected to the ground. • No risk that the 24 V feed is at a high level in relationship to the ground. This is not unusual since there is high static electricity. Beijer Electronics, MAEN249B... -
Page 29: Galvanic Isolation
Use external units to improve communication and achieve galvanic isolation. Westermo has good industry-standard insulators that are also insulated from the 24 V DC feed. Beijer Electronics, MAEN249B... - Page 30 24 V feed, disturbances and grounding currents from the 0 V on the 24 V side disrupt the communication. Using this type of unit solves one problem but creates a larger problem! A substandard installation may work now, but problems may arise when other devices are connected. Beijer Electronics, MAEN249B...
-
Page 31: Cable And Bus Termination Rs-485
CAN nodes with 118 Ohm... 130 Ohm resistors. The recommended resistor value is 120 Ohm/1%/0.25W on each end. • Place the termination resistor near the CAN bus connector (as close as possible). • This product has no integrated termination resistors. They must be added externally. Beijer Electronics, MAEN249B... -
Page 32: Restrictions And Recommendations
Use the screensaver functionality (see SW manual). • Changing constantly between static and dynamic images. • Avoid excessive brightness differences between foreground and background elements. • Use colors with similar brightness. • Use complementary colors in follow-up images. Beijer Electronics, MAEN249B... - Page 33 Head office Beijer Electronics AB Box 426 201 24 Malmö, Sweden www.beijerelectronics.com / +46 40 358600...
