Campbell Hausfeld IN727601AV Easy Setup Manual

2-1/2 inch 35° Finish Nailer
CHN70600
Setup
Easy Setup Guide
Projects are easier with
Campbell Hausfeld products.
Thank you for deciding to purchase a
Campbell Hausfeld product. We are dedicated
to providing tools that help you to complete your
projects Like a Pro.
© 2009 Campbell Hausfeld/Scott Fetzer © 2009 Campbell Hausfeld/Scott Fetzer
3
Load
fasteners. See manual for further information regarding length and type of fasteners.
Pull pusher back
until it latches.
Setup Like a Pro
1
Visit us at chpower.com
Close
regulator,
ON
Allow
Like a Pro
maximum pressure.
NOTICE: To operate this tool you will need
at least a 1 gallon compressor.
IN727601AV 6/09
Nail Pusher
Latch Button
Load nails. Press
allow pusher to ride against nails.
2
pressure Attach
Turn hose to regulator
compressor and outlet. Adjust
tank to reach regulator knob so
outlet pressure is
between 70 psi and
120 psi.
4
Attach
hose to nailer inlet.
pusher latch button and
air
70 120
psi psi
Battery Replacement
coupler on air
performing any maintenance or repair, clearing a jam,
loading, unloading, or moving the tool to a new location.
Disconnect the tool from air source. Remove screw
and battery compartment cover. Insert two (2) new
batteries in the proper orientation. Do not mix old
and new batteries. Close cover. Replace screw.
CHN70600 — Air Powered Angle Finish Nailer
Screw
Always disconnect the tool from
the power source when unattended,
