CONNECTING THE D-RGB LED STRIP
D-RGB LED Connector
STEP 1
Plug in the 3-pin D-RGB connector from your GPU Water Block to a
D-RGB header on your motherboard or controller. The LED Strip will
only work if the pin layout on the header is as follows: +5V, Digital,
Empty, Ground.
D-RGB Header
RGB Header
STEP 1
- 7 -
Incorrect installation or installation to the incorrect header
may result in damage to the LED Strip or header!
