INSTALLING THE ASSEMBLY - OPTION 2
50mm
Vibration damper
Screw M4x4 DIN7984
- 5 -
The assembly can be mounted on any flat surface inside your computer
chassis. One must drill four (4) 4.2mm holes using powerdrill in a 50x50mm
square pattern. Please follow these steps:
1. Screw on Vibration Dampers on Custom SPC Screws.
2. Drill four (4) 4.2mm holes into the chassis.
3. Use enclosed M4×4mm screws to secure the pump to the chassis.
