Compressor Case - Midea COMPACT Series Service Manual

Thermostat
1） Remove the rotary knob，the cap and screw on the
assembly
thermostat-box
Remove the connector and dismantle the
2）
thermostat assembly
-box
Remove the thermostat
3）
Loosen the thermostat fastening screw
4）
5 ）
Remove the thermostat-box cover and replace
the thermostat.

8.7 Compressor case

Rear cover and compressor case
Rear cover
Compressor and the cooling system pipe
panel
-box
21
Service Manual_2018-V1.0
