5) Dismantle the lower hinge and adjustable leg.
4) 6) Install the lower hinge and adjustable leg on lower left
side of cabinet.
7)Put the door on lower hinge vertically, and validate the
gas tightness of door gasket, take out the spare upper
left hinge and hinge cover from accessory bag, then
install the upper left hinge by fitting screws, finally to
install the hinge cover, and cover the hinge hole cap on
upper right side.
3.6 Installation of handle
Installation of handle
Installation of handle
3.7 Installation of door lock
Installation of door lock
Installation of door lock
3.8 Adjustment to level the door
Adjustment to level the door
Adjustment to level the door
3.9 Adjustment to shelves
Adjustment to shelves
Adjustment to shelves
Service Manual_2018-V1.0
