Campbell Hausfeld CHN101 Operating Instructions Manual

See Warranty on page 8 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
REGISTER YOUR PRODUCT ONLINE NOW!
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . .1
Safety Guidelines . . . . . . . . . . . . . . . . .1
General Safety Information . . . . . . . . .1
Specifications. . . . . . . . . . . . . . . . . . . . .2
Operating The Nailer . . . . . . . . . . . . . .3
Operational Mode . . . . . . . . . . . . . . . .4
User-Maintenance Instructions . . . . . .5
Troubleshooting . . . . . . . . . . . . . . . . . .7
Limited Warranty . . . . . . . . . . . . . . . . .8
Description
This nailer is designed for decorative
trim, molding, window casings,
furniture trim and picture frame
assembly. Features include: no-mar tip,
adjustable exhaust, single sequential
trigger, quick clear nose, and an
adjustable depth of drive mechanism.
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit. Make sure
to tighten fittings, bolts, etc., before
putting unit into service.
READ & FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
DO NOT DISCARD
Campbell Hausfeld Tools meet or exceed Industries' Standards as set forth by the American National Standard
Institute/International Staple, Nail and Tool Association in ANSI/ISANTA SNT-101-2002.
© 2012 Campbell Hausfeld/Scott Fetzer
Safety Guidelines
This manual contains information
that is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help
recognize this information, observe the
following symbols.
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
information, that if not followed, may
cause damage to equipment.
NOTE: Information that requires special
attention.
General Safety Information
INSTRUCTIONS PERTAINING TO A
RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS
should always be followed, including
the following:
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.chpower.com
Brad Nailer
http://www.chpower.net/reg
Danger indicates an
imminently
Model CHN101
Warning indicates a
potentially
Locate model and date code on
tool and record below:
Model No.: _____________________
Caution indicates a
Date Code: _____________________
potentially
Notice indicates
important
CALIFORNIA PROPOSITION 65
contain chemicals known to the State
of California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
dust when you cut, sand, drill
When using tools,
or grind materials such as
basic precautions
wood, paint, metal, concrete,
cement, or other masonry. This dust
often contains chemicals known to
cause cancer, birth defects, or other
reproductive harm. Wear protective
gear.
CHN101
1-1/4 inch
Retain these numbers for
future reference.
This product or
its power cord may
You can
create
IN700901AV 10/12
