16 About the units and options

In this chapter

16.1 Overview: About the units and options

16.2 Identification label: Outdoor unit

REYQ8~20+REMQ5U7Y1B
VRV IV+ heat recovery
4P561154-1A – 2020.10
16.1 Overview: About the units and options .................................................................................................................................
16.2 Identification label: Outdoor unit...........................................................................................................................................
16.3 About the outdoor unit ..........................................................................................................................................................
16.4 System layout..........................................................................................................................................................................
16.5 Combining units and options..................................................................................................................................................
16.5.1 About combining units and options.......................................................................................................................
16.5.2 Possible combinations of indoor units...................................................................................................................
16.5.3 Possible combinations of outdoor units ................................................................................................................
16.5.4 Possible options for the outdoor unit....................................................................................................................
This chapter contains information about:
▪ Identification of the outdoor unit
▪ Where the outdoor unit fits in the system layout
▪ With which indoor units and options you can combine the outdoor units
▪ Which outdoor units have to be used as standalone units, and which outdoor
units can be combined
Location
5~12 HP
Model identification
Example: R E Y Q 18 U7 Y1 B [*]
Code
R Outdoor air cooled
E Heat recovery
Y Y=Single or multi module
M=Multi module only
Q Refrigerant R410A
18 Capacity class
