Daikin VRV IV+ Installer And User Reference Manual page 115

REYQ8~20+REMQ5U7Y1B
VRV IV+ heat recovery
4P561154-1A – 2020.10
Model
REMQ5
REYQ8
REYQ10
REYQ12
REYQ14
REYQ16
REYQ18
REYQ20
Model
REYQ10
REYQ13
REYQ16
REYQ18
REYQ20
REYQ22
REYQ24
REYQ26
REYQ28
REYQ30
REYQ32
REYQ34
REYQ36
REYQ38
REYQ40
REYQ42
REYQ44
REYQ46
REYQ48
REYQ50
REYQ52
REYQ54
For all models:
▪ Phase and frequency: 3N~ 50 Hz
▪ Voltage: 380~415 V
19
Single outdoor unit
Minimum circuit
ampacity
16.1 A
16.1 A
22.0 A
24.0 A
27.0 A
31.0 A
35.0 A
39.0 A
Multi outdoor units
Minimum circuit
ampacity
30.0 A
30.0 A
30.0 A
37.0 A
39.0 A
46.0 A
46.0 A
51.0 A
55.0 A
59.0 A
62.0 A
66.0 A
70.0 A
74.0 A
81.0 A
84.0 A
86.0 A
89.0 A
93.0 A
97.0 A
101.0 A
105.0 A
Electrical installation
|
Recommended fuses
20 A
20 A
25 A
32 A
32 A
40 A
40 A
50 A
Recommended fuses
40 A
40 A
40 A
50 A
50 A
63 A
63 A
63 A
63 A
80 A
80 A
80 A
80 A
100 A
100 A
100 A
100 A
100 A
125 A
125 A
125 A
125 A
Installer and user reference guide
115
