20.3.4 Example: Automatic mode during heating

Installer and user reference guide
142
T
c
49°C
C
46°C
D
A Virtual load curve (default automatic mode peak capacity)
B Load curve
C Virtual target value (initial condensation temperature value automatic mode)
D Design temperature
E Load factor
F Outside air temperature
T Condensing temperature
c
Quick
Powerful
Mild
Room temperature evolution:
A
F E
B
A Indoor unit set temperature
B Operation start
C Operating time
D Mild
A
B
2°C
D
E
100%
70%
F
C
