20.2.2 Field setting components

REYQ8~20+REMQ5U7Y1B
VRV IV+ heat recovery
4P561154-1A – 2020.10
Push buttons
Performing special actions (automatic refrigerant charge, test run, etc.) and making
field settings (demand operation, low noise, etc.) happens by way of operating the
push buttons.
See also:
▪ "Field setting components" [
▪ "To access the field setting
PC configurator
For VRV IV heat recovery system it is alternatively possible to make several
commissioning field settings through a personal computer interface (for this,
option EKPCCAB* is required). The installer can prepare the configuration (off-site)
on PC and afterwards upload the configuration to the system.
See also: "To connect the PC configurator to the outdoor
Mode 1 and 2
Mode
Mode 1
(monitoring settings)
Mode 2
(field settings)
See also:
▪ "To access mode 1 or
4
▪ "To use mode 1" [ 125]
4
▪ "To use mode 2" [ 126]
▪ "Mode 1: Monitoring
▪ "Mode 2: Field settings" [
Location of the 7‑segment displays, buttons and DIP switches:
a b
BS1 BS2 BS3
BS1 MODE: For changing the set mode
BS2 SET: For field setting
BS3 RETURN: For field setting
DS1, DS2 DIP switches
4
123]
4
components" [ 124]
Mode 1 can be used to monitor the current situation of
the outdoor unit. Some field setting contents can be
monitored as well.
Mode 2 is used to change the field settings of the
system. Consulting the current field setting value and
changing the current field setting value is possible.
In general, normal operation can be resumed without
special intervention after changing field settings.
Some field settings are used for special operation (e.g., 1
time operation, recovery/vacuuming setting, manual
adding refrigerant setting, etc.). In such a case, it is
required to abort the special operation before normal
operation can restart. It will be indicated in below
explanations.
4
2" [ 124]
4
settings" [ 127]
4
129]
DS1 DS2
X27A
20 Configuration
|
4
unit" [ 137].
Description
Installer and user reference guide
123
