www.wester mo.com
Lynx L108/208-F2G-S2
Industrial Ethernet 8-Port Device Server Switch
OS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lynx L108-F2G-S2 and is the answer not in the manual?

Questions and answers

Related Manuals for Westermo Lynx L108-F2G-S2

Summary of Contents for Westermo Lynx L108-F2G-S2

  • Page 1 www.wester mo.com Lynx L108/208-F2G-S2 Industrial Ethernet 8-Port Device Server Switch...

  • Page 2: Table Of Contents

    Table of Contents 1. General Information ................ 4 1.1. Legal Information ..............4 1.2. About This Guide ..............4 1.3. Software Tools ..............4 1.4. License and Copyright for Included FLOSS ......... 4 1.5. WeOS Management Guide ............4 2. Safety and Regulations ..............5 2.1.
  • Page 3 5.2. Type Tests and Environmental Conditions ......... 29 6. Revision Notes ................32 Lynx L108/208-F2G-S2...

  • Page 4: General Information

    Westermo reserves the right to revise this document or withdraw it at any time without prior notice. Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused.

  • Page 5: Safety And Regulations

    2. Safety and Regulations 2.1. Warning Levels Warning signs are provided to prevent personal injuries and/or damages to the product. The following levels are used: Level of warning Description Consequence Consequence personal injury material damage Indicates a potentially Possible death or major Major damage to the hazardous situation injury...

  • Page 6: Safety Information

    WARNING - PROTECTIVE FUSE It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personell. WARNING - POWER SUPPLY CONNECTION There are safety regulations on which power sources that shall be used in conjunction with the product.
  • Page 7 WARNING - REDUCE THE RISK OF FIRE To reduce the risk of fire, use only telecommunication line cords with a cable diameter of AWG 26 or larger. Regarding power cable dimensions, see Interface Specifications. CAUTION - CLASS 1 LASER PRODUCT Do not look directly into a fibre optical port or any connected fibre, although the product is designed to meet the Class 1 Laser regulations and complies with 21 CFR 1040.10 and 1040.11.

  • Page 8: Care Recommendations

    If the product is used in a manner not according to specification, the protection provided by the equipment may be impaired. If the product is not working properly, contact the place of purchase, nearest Westermo distributor office or Westermo technical support.

  • Page 9: Compliance Information

    2.5. Compliance Information 2.5.1. Agency Approvals and Standards Compliance Type Approval/Compliance • EN/IEC 61000-6-1, Immunity residential environments • EN/IEC 61000-6-2, Immunity industrial environments • EN/IEC 61000-6-3, Emission residential environments • EN/IEC 61000-6-4, Emission industrial environments • EN 50121-4/IEC 62236-4, Railway signalling and telecommunications apparatus Safety •...

  • Page 10: Corrosive Environment

    Class C Class D Class E Remarks Temperature Relative humidity Vibration Mechanical shock Dielectric strength Tested with 1.5 kVAC rms Table 4. AREMA Part 11.5.1. - Environmental Class External Internal Enclosure port Radiated RF immunity Power Frequency Magnetic Field Pulse Magnetic Field DC power port EFT/Burst Surge (1.2/50μs)

  • Page 11: Simplified Declaration Of Conformity

    2.5.5. Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives. The full EU declaration of conformity and other detailed information is available at www.westermo.com/support/product-support.

  • Page 12: Product Description

    -40 to +70°C (-40 to +158°F) can be achieved with no moving parts or cooling holes in the case. The Lynx series has been tested both by Westermo and external test institutes to meet many EMC, isolation, vibration and shock standards, all to the highest levels suitable for heavy industrial environments and rail trackside applications.

  • Page 13: Hardware Overview

    3.3. Hardware Overview Description Description LED indicators SFP transceivers USB connection Power connection I/O connection Ethernet connection RS-232 connection RS-232 and RS-422/485 connection Figure 3. Location of interface ports and LED indicators Description Description I/O connection Console port Accessorie cable, art. no. 1211-2027 Figure 4.

  • Page 14: Connector Information

    3.4. Connector Information 3.4.1. Ethernet Connection TX Illustration Pin no. Signal Direction Description In/Out Transmitted/Received data In/Out Transmitted/Received data In/Out Transmitted/Received data Not connected Not connected In/Out Transmitted/Received data Not connected Not connected Shield Connected to PE Table 6. Ethernet connection TX 3.4.2.

  • Page 15: Rs-232 Connection (Dce)

    The Status output is a potential free, opto-isolated, normally closed, solit-state relay. This can be configured to monitor various alarm events within the unit, see WeOS Management Guide. An external load in series with an external voltage source is required for proper functionality.

  • Page 16: Rs-422/485 Connection

    3.4.5. RS-422/485 Connection Illustration Pin no. Signal Direction Description RS-422 (4- RS-485 (2- wire) wire) T+/R+ Out/In RS-422: Transmit RS-485: Transmit/ Receive T-/R- Out/In RS-422: Transmit RS-485: Transmit/ Receive Pin 8 Pin 1 RS-422: Receive Not used Not used RS-422: Receive Not used Not used Table 10.

  • Page 17: Usb Connection

    When the unit is powered off or during reboot, any internal termination will be disconnected from the signal lines. NOTE NOTE - The port is configurable for both RS-232 and RS-422/485, hence no fail-safe biasing is available for RS-422/485 signals. 3.4.6.

  • Page 18: Led Indicators

    Supply voltage levels must be ensured externally. A green LED indicator may not guarantee a valid operating voltage level Table 12. LED indicators 3.6. SFP Transceivers The product supports UL and IEC certified transceivers only. See Westermo's modular transceivers datasheets 100 Mbit and 1 Gbit for supported SFP transceivers, which can be Lynx L108/208-F2G-S2...

  • Page 19: Supported Transceivers

    3.7. Supported Transceivers Firmware prior to 4.4.0 accepts Westermo branded transceivers only. From 4.5.0 other transceivers are accepted with a notice and the product will no longer be UL approved.

  • Page 20: Dimensions

    3.9. Dimensions Dimensions are stated in mm and are regardless of Lynx model. 96 ±1 52 ±1 92 ±1 Figure 8. Dimensional drawing Lynx L108/208-F2G-S2...

  • Page 21: Installation

    4. Installation 4.1. Mounting This product should be mounted on a 35 mm DIN-rail, which is horizontally mounted inside an apparatus cabinet or similar. It is recommended that the DIN-rail is connected to ground. Snap on the product to the DIN-rail according to the figure. Figure 9.

  • Page 22: Cooling

    This product runs the Westermo Operating System (WeOS) which provides several management tools that can be used for configuration of the unit. • WeConfig tool This is a custom Westermo tool used for discovery of attached Westermo product. • Web Configuration of the product using the web browser.

  • Page 23: Configuration Via A Web Browser

    Username: admin Password: westermo Once logged in, use the extensive integrated help function describing all configuration options. Two common task when configuring a new switch is to assign appropriate IP settings, and to change the password of the admin account.
  • Page 24 • Acknowledge that you wish to conduct the factory reset by unplugging the Ethernet cables. The ON LED will stop flashing. This initiates the factory reset process, and after approximately 1 minute the product will restart with factory default settings. When the product has booted up, the ON LED will show a green light, and is now ready to use.

  • Page 25: Specifications

    5. Specifications 5.1. Interface Specifications DC, Power port L108-F2G-S2-12VDC: Lx08-F2G-S2: Rated voltage 12 - 24 VDC 24 - 48 VDC Operating voltage 9.8 - 36 VDC 19 - 60 VDC Rated current 470 mA (820 mA) at 12 VDC (with 250 mA (380 mA) at 24 VDC 500 mA USB load) (with 500 mA USB load)
  • Page 26 Ethernet TX Electrical specification IEEE std 802.3 Data rate 10 Mbit/s, 100 Mbit/s, manual or auto Duplex Full or half, manual or auto Circuit type TNV-1 Transmission range Up to 150 m with CAT5e cable or better Isolation All other ports Connection RJ-45, auto MDI/MDI-X Cabling...
  • Page 27 RS-422/485 Electrical specification Configurable for EIA RS-232 or EIA RS-422/485 Data rate 50 bit/s - 2 Mbit/s Data format 7 or 8 data bits, odd, even or none parity, 1 or 2 stop bits (2 stop bits only when no parity is set) Circuit type TNV-1 Transmission range...
  • Page 28 LVTTL-level (service port, shall not be connected during normal operation. Only to be used during maintenance.) Data rate 115.2 kbit/s Circuit type SELV Data format 8 data bits, no parity, 1 stop bit, no flow control Connection 2.5 mm jack, use only Westermo cable 1211-2027 Lynx L108/208-F2G-S2...
  • Page 29 5.2. Type Tests and Environmental Conditions Environmental Basic standard Description Test levels phenomena EN 61000-4-2 Enclosure Contact: ±6 kV Air: ±8 kV Fast transients EN 61000-4-4 Power port ± 2 kV Ethernet Status out/Digital in Serial ports Enclosure Surge EN 61000-4-5 Power port L-L: ±...
  • Page 30 Environmental Basic standard Description Test levels phenomena Compass safe distance Enclosure Standard compass (5.4°/H deviation) = 15 cm Steering/standby steering / emergency compass (18°/H deviation) = 10 cm Dielectric strength EN 60950-1 Power port to all 1.5 kVrms, 50 Hz, 1 min other ports Ethernet ports to all other ports...
  • Page 31 Environmental Basic Description Test levels phenomena standard Temperatures EN 60068-2-1 Operational -40 to +70°C (-40 to +158°F) EN 60068-2-2 Storage and -50 to +85°C (-58 to +185°F) transport Humidity EN 60068-2-30 Operational 5-95% relative humidity Storage and transport Altitude Operational 2000 m/70 kPa Service life Operational...
  • Page 32 Date Change description Rev N 2020-10 Westermo logo updated, illustrations updated from brown to blue, 2.2 Safety Information updated (text and warnings), 2.3 Care Recommendations updated, old 2.4 Maintenance deleted, 2.5.1 Agency Approvals and Standards Compliance updated, 3.1 Product Description updated, 3.6 SFP Transceivers updated, 3.7 Supported Transceivers...
  • Page 33 Lynx L108/208-F2G-S2...
  • Page 34 Lynx L108/208-F2G-S2...
  • Page 35 Lynx L108/208-F2G-S2...
  • Page 36 Westermo • SE-635 35 Stora Sundby, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com 6643-2220 REV. N 2020 10 Westermo Network Technologies AB, Sweden...
