- Page 1 Lynx L106-S2 and L206-S2 Industrial Ethernet 6-Port Device Server Switch...
-
Page 2: Table Of Contents
4.4. Getting Started ..............18 4.5. Configuration Via a Web Browser ..........19 4.6. Factory Default ..............19 5. Specifications ................21 5.1. Interface Specifications ............21 5.2. Type Tests and Environmental Conditions ......... 24 6. Revision Notes ................26 Lynx L106-S2 and L206-S2... -
Page 3: General Information
Westermo reserves the right to revise this document or withdraw it at any time without prior notice. Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 4: Safety And Regulations
No personal injury Minor damage to the to avoid misuse of the product product, confusion or misunderstanding NOTICE Used for highlighting general, No personal injury Minor damage to the but important information product NOTE Table 1. Warning levels Lynx L106-S2 and L206-S2... -
Page 5: Safety Information
WARNING - PROTECTIVE FUSE It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personell. WARNING - POWER SUPPLY CONNECTION There are safety regulations on which power sources that shall be used in conjunction with the product. -
Page 6: Care Recommendations
• Use a dry or slightly water-damp cloth to clean the product. Do not use harsh chemicals, cleaning solvents or strong detergents. • Do not paint the product. Paint can clog the product and prevent proper operation. Lynx L106-S2 and L206-S2... -
Page 7: Product Disposal
If the product is used in a manner not according to specification, the protection provided by the equipment may be impaired. If the product is not working properly, contact the place of purchase, nearest Westermo distributor office or Westermo technical support. -
Page 8: Corrosive Environment
2.5.4. Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives. The full EU declaration of conformity and other detailed information is available at www.westermo.com/support/product-support. -
Page 9: Product Description
-40 to +70°C (-40 to +158°F) can be achieved with no moving parts or cooling holes in the case. The Lynx series has been tested both by Westermo and external test institutes to meet many EMC, isolation, vibration and shock standards, all to the highest levels suitable for heavy industrial environments and rail trackside applications. -
Page 10: Hardware Overview
Power connection I/O connection Ethernet connection RS-232 connection Figure 3. Location of interface ports and LED indicators Description Description I/O connection Console port Accessorie cable, art. no. 1211-2027 Figure 4. Location of interface ports, bottom view Lynx L106-S2 and L206-S2... -
Page 11: Connector Information
Product marking Direction Description Status + Output Alarm relay (status) contact Status - Output Alarm relay (status) contact Digital in + Input Digital in + Digital in - Input Digital in - Table 5. I/O connection Lynx L106-S2 and L206-S2... -
Page 12: Rs-232 Connection (Dce)
Pin no. Signal Direction Description Data Set Ready Data Carrier Detect Data Terminal Ready Signal Ground, not chassis ground Receive Data Pin 8 Pin 1 Transmit Data Clear To Send Request To Send Table 6. RS-232 connection Lynx L106-S2 and L206-S2... -
Page 13: Rs-422/485 Connection
Lynx is equipped with with an internal termination that is configurable through software in RS-422/485 mode. The following termination schemes are supported: No termination Terminate Rx Terminate Tx Terminate Tx and Rx Figure 6. RS-422 termination scheme No termination Termination Figure 7. RS-485 termination scheme Lynx L106-S2 and L206-S2... -
Page 14: Connection To The Console Port
3.4.6. Connection to the Console Port The console port can be used to connect to the CLI (Command Line Interface). 1. Connect the serial diagnostic cable to the console port (use only Westermo cable 1211-2027). 2. Connect cable to your computer (USB port, if drivers are needed they can be downloaded from the Westermo web). -
Page 15: Led Indicators
Port alarm and no link. Or if FRNT or RSTP mode, port is blocked. Supply voltage levels must be ensured externally. A green LED indicator may not guarantee a valid operating voltage level Table 10. LED indicators Lynx L106-S2 and L206-S2... -
Page 16: Dimensions
3.6. Dimensions Dimensions are stated in mm and are regardless of Lynx model. 96 ±1 52 ±1 92 ±1 Figure 8. Dimensional drawing Lynx L106-S2 and L206-S2... -
Page 17: Installation
Figure 9. Mounting of product 4.2. Removal of Product This product has an integrated DIN-clip. To remove the product, press down the support at the back with a screwdriver and lift it off the DIN-rail. Figure 10. Removal of product Lynx L106-S2 and L206-S2... -
Page 18: Cooling
This product runs the Westermo Operating System (WeOS) which provides several management tools that can be used for configuration of the unit. • WeConfig tool This is a custom Westermo tool used for discovery of attached Westermo product. • Web Configuration of the product using the web browser. -
Page 19: Configuration Via A Web Browser
To go ahead with factory reset: NOTE Do not power off the product while the factory reset process is in progress. Lynx L106-S2 and L206-S2... - Page 20 • To skip the factory reset process, just wait for approximately 30 seconds (after the ON LED starts flashing RED) without unplugging the Ethernet cables. The product will conduct a normal boot with the existing settings. Lynx L106-S2 and L206-S2...
-
Page 21: Specifications
Full or half, manual or auto Circuit type TNV-1 Transmission range Up to 150 m with CAT5e cable or better Isolation All other ports Connection RJ-45, auto MDI/MDI-X Cabling Shielded CAT5e or better is recommended Conductive chassis Number of ports Lynx L106-S2 and L206-S2... - Page 22 To minimise the risk of interference, a shielded cable is recommended when the cable is located inside 3 m boundary or the cable is longer than 30 m and inside 10 m boundary to the rails and connected to this port. Lynx L106-S2 and L206-S2...
- Page 23 USB receptable connector type A Console port Electrical specification LVTTL/LVCMOS-level Data rate 115.2 kbit/s Circuit type SELV Data format 8 data bits, no parity, 1 stop bit, no flow control Connection 2.5 mm jack, use only Westermo cable 1211-2027 Lynx L106-S2 and L206-S2...
-
Page 24: Type Tests And Environmental Conditions
CISPR 16-2-1 Power port Class B/DNV bridge ANSI C63,4 Ethernet Class B (FCC Part 15b) Dielectric strength EN 60950-1 Power port to all 1.5 kVrms, 50 Hz, 1 min other ports Ethernet ports to all other ports Lynx L106-S2 and L206-S2... - Page 25 0.7 kg Degree of protection EN 60529 Enclosure IP40 Cooling Convection Refer to "Safety and Regulations" chapter regarding touch temperature Might require Ethernet cables to be fastened close to the unit. Table 12. Environmental and mechanical conditions Lynx L106-S2 and L206-S2...
-
Page 26: Revision Notes
Change description Rev. H 2020-10 Westermo logo updated, illustrations updated from brown to blue, new information structure throughout the manual, 1.2 About This Guide - new chapter, 2 Safety and Regulations - entire chapter updated, 3.1. Product Description updated, 3.2. Available Models - new chapter, 4.1 Mounting updated, 4.2 Removal of Product updated... - Page 27 Lynx L106-S2 and L206-S2...
- Page 28 Westermo • SE-635 35 Stora Sundby, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com 6643-2240 REV. I 2020 10 Westermo Network Technologies AB, Sweden...
