  • Page 1 Gima S.p.A. Via Marconi, 1 - 20060 Gessate (MI) Italy gima@gimaitaly.com - export@gimaitaly.com www.gimaitaly.com PROFESSIONAL MEDICAL PRODUCTS ECG PALMARE CARDIO-B BLUETOOTH CON SOFTWARE CARDIO-B BLUETOOTH PALM ECG WITH SOFTWARE ECG DE POCHE CARDIO-B BLUETOOTH AVEC LOGICIEL ECG PALMAR CARDIO-B BLUETOOTH CON SOFTWARE Manuale d’uso - User manual...
  • Page 2 ENGLISH WARNING 1. Check the device to make sure that there is no visible damage that may affect user’s safety and measurement performance. Stop using the unit, when there is obvious damage. 2. Do NOT make diagnosis oneself by the measurement and measurement results, always consult the doctor if abnormal information is presented frequently.
  • Page 3 ENGLISH 7. Display screen: display ECG waveforms and data. 8. Metal Electrode III ECG Lead wire connector: for connecting to lead wire. Data interface: for connecting Mini USB data cable. 1.2 Name and Model Cardio-B bluetooth palm ECG with software 1.3 Structure Cardio-B palm ECG monitor consists of main board, panels and electrodes.
  • Page 4 ENGLISH enter into measuring screen, as shown in Figure 3-4. There are 6 tool buttons, press navigation key to shift cursor and press “ OK” to confirm. Each functional button will be defined as follows: Measure: detect ECG waveform and HR value, and analyze whether the ECG waveform is normal.
  • Page 5 ENGLISH Palm Measurement Palm Measurement is recommended in terms of convenient and quick measurement. Hold the device with right hand. Make sure that the palm and fingers touch the metal electrode I and II reliably. Press the electrode III closely against the center of the left palm. The ECG signal detected by Palm Measurement is equivalent to Lead I ECG signal.
  • Page 6 ENGLISH On-screen display: 1. “16: 14: 32”: Current time. 2. “X1”: ECG waveform gain. “X1/2”: Waveform scaled with half of the basic gain; “X1”: Waveform scaled with basic gain; “X2”: Waveform scaled with twice of the basic gain “X3”: Waveform scaled with three times of the basic gain 3.
  • Page 7 ENGLISH “ECG Viewer Manager” for detailed operation procedure.). The data measured in wireless real-time transmission status won’t be stored in the unit. 3. If there is no operation after the continuous measurement has been carried out for 3 minutes, the unit will adopt power- saving mode automatically (the screen will darken), but the measurement won’t be interrupted.
  • Page 8 ENGLISH be displayed. “1/2”: the screen page description for waveform review of continuous measurement. “1”: current page, “2”: total page. 4. “ ”: Indicating that ECG filter mode is “Enhanced”. 5. “ ”: Status of battery power 6. “ ”: Reviewed ECG waveform 7.
  • Page 9 ENGLISH 3.4.3 Measurement Result Table ECG Measurement Result Descriptions Waveform No irregularity found Suspected a little fast beat Suspected fast beat Suspected short run of fast beat Suspected a little slow beat Suspected slow beat Suspected occasional short beat interval Suspected irregular beat interval Suspected fast beat with short beat Suspected slow beat with short beat interval...
  • Page 10 ENGLISH ECG Measurement Result Descriptions Waveform Waveform baseline wander Suspected fast beat with baseline wander Suspected slow beat with baseline wander Suspected occasional short beat interval with baseline wander Suspected irregular beat interval with baseline wander Poor Signal, measure again 3.5 Data Management 3.5.1 Data Deletion Select “Memory”...
  • Page 11 ENGLISH Figure 3-22 Figure 3-23 Figure 3-21 Upload Data Screen 3.6.1 Time/Date Setting 1.On system setting screen, select “Time/date” with Navigation Key, then press “ OK” button to enter time and date setting screen (date format: dd/mm/yyyy), as shown in Figure 3-24. 2.
  • Page 12 ENGLISH 3.6.6 Wireless Setting 1. On system setting screen, select “Wireless” to enter wireless setting screen, as shown in Figure 3-29. 2. Press the Navigation Key to turn on or turn off the wireless function. 3. Press “ OK” button to save setting and return to the upper level menu screen. Downloading the APP software for smart phone The terminal devices such as smart phone can be used to receive data from the Easy ECG Monitor in real-time, and store the received data, review the stored...
  • Page 13 ENGLISH 4 Technical Specifications 4.1 ECG Measurement Number of channels: Single channel ECG signal Electrodes: 3 embedded metal electrodes or using 3 adhesive ECG electrodes by connection to the lead wire. Measurement modes: the detecting ECG signal can be detected by the following lead selection: Lead I (between right hand and left hand);...

  • Page 14: Troubleshooting

    ENGLISH This device should be transported by land (vehicle or railway) or air in accordance with the contractual terms. Do not hit or drop it with force and protect it from sunlight and rain. Keep it away from corrosive substances, explosive substances, high/low temperature and moisture. If the device gets wet or has water steam, please stop operating it.

  • Page 15: Symbol Description

    ENGLISH 9 Key of Symbols Symbol Description Symbol Description Heart Rate Caution: read instructions (warnings) carefully (Unit: beats per minutes) Measure mode: enhanced Product code Battery indicator Serial number Wireless transmission Manufacturer mark Full memory mark Date of Manufacturing Return button Authorized representative in the European community Power button Keep in a cool, dry place...
  • Page 16 The warranty is valid for 12 months from the date of supply of GIMA. During the period of validity of the warranty, GIMA will repair and/or replace free of charge all the defected parts due to production reasons.
  • Page 17 ENGLISH Premature Nodal Contraction and Premature Ventricular Contraction (PVC), which needed to be judged by experts. Symptom: The heart beat is arrhythmic, it occurs as the phenomenon that the heart suddenly beats and then stops for a while. Some people have palpitation or have no symptom.
