9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | +1-406-549-0769
www.aquacreek.com
PART #: F-005SLU-05
US PATENT NUMBER: [D507,769 S]
400 LB. [181 kg] MAXIMUM WEIGHT CAPACITY
FOR INDOOR OR OUTDOOR USE
MANDATORY
LEAVE THIS MANUAL WITH LIFT OWNER
ADA COMPLIANT
READ CAREFULLY
Check entire box and inside all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical all parts be carefully inspected by the installer prior to installation to ensure no
damage occurred in transit and a damaged part is not used. If any damage occurred in transit,
Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may aff ect the safety of the user.
1
Copyright © 2020 Aqua Creek Products All Rights Reserved
Revised 6/25/20
Advertisement
Related Manuals for Aqua Creek Products SPA LIFT ULTRA
Summary of Contents for Aqua Creek Products SPA LIFT ULTRA
- Page 1 If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may aff ect the safety of the user. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 2 Supervise children at all times. No jumping or diving from the lift. Seat may be hot, use caution when entering. Keep covered when not in use. Inspect and clean before use. INDOOR BATTERY CHARGER: AMPERAGE = 0.65 FREQUENCY = 60 24 VOLT BATTERY AMPERAGE = 8 IP RATING = IPX5 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 3 Basic Troubleshooting Spa Lift Ultra Components 1. Spa Lift Ultra 2. 24 Volt Battery 3. Hand Remote 4. Safety Belt 5. Hardware bag with anchor inserts & anti-seize (if ordered w/ anchor) NOTE: For wood deck applications refer to Wood Deck Anchor Manual (F-107UEWDA) Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 4 (2500 PSI) EPOXY TOP MATT TO EXISTING SLAB (4" MIN. EMBED, 3-SIDES) 3'-6" 4" POOL/SPA (MIN) WALL 10.75" 10.75" 3'-6" 10.75" 10" 1" x 8" ANCHOR INSERTS FIGURE 1 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 5 3/8" FLAT WASHER 3/8" NYLOCK ACTUATOR 1/2" X 3" SHOULDER BOLT 5/16" FLAT WASHER 5/16" NYLOCK 3/8" X 1 1/4" SHOULDER BOLT MAST ASSEMBLY LOWER ATTACHMENT POINT FIGURE 5 FIGURE 4 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 6 NOTE: With the lift fully assembled, run the lift fully out and back in 3-5 times, without weight, for the lifts “break in” cycle period. LOOP ON TOP FOR EASY ACCESS FIGURE 8 THREAD THROUGH SLOTS AND PINCH FIGURE 9 TOGETHER TO HOLD Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 7 2. Using the supplied 1/4” hardware, fasten the legrest assembly to the 2 x 2 tubing. LEGREST ASSEMBLY 1/4" FLAT WASHER 1/4" LOCK WASHER 1/4" X 3/4" THUMB SCREW LEGREST IN LEGREST OUT Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 8 Note: the lift will not retract if the battery is not fully charged or if the control box is not working. The emergency button only overrides the remote handset. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 9 Pinch Point Locations CAUTION! PINCH POINT AREAS! LIFT TO BE STICKERED ON BOTH SIDES OF ARMS. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 10 4. Do NOT expose the battery to long periods of direct sunlight. Heat will shorten your battery life. Optimum operating range is between 5 degrees Celsius (40 degrees F) and 40 degrees Celsius (105 degrees F.) 5. Never drop or bump the battery pack. This may result in loose or damaged internal connections, and may damage the battery terminals. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 11 SCT-135-01 FINGER GUARD WFC 3/4 3/4 CUSTOM WASHER BAJ1-U026-00 24V BATTERY NN 3/4 3/4-10 NYLOCK NUT BH 1/4 X 3/4 1/4-20 X 3/4 HEX BOLT F-UBC BATTERY/CONTROL BOX COVER Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 12 SHALL AQUA CREEK’S LIABILITY EXCEED THE ENTIRE AMOUNT PAID TO AQUA CREEK BY THE ORIGINAL PURCHASER FOR THE FAILED OR DEFECTIVE PRODUCT. IN NO EVENT SHALL AQUA CREEK PRODUCTS, LLC BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, INDIRECT, PUNITIVE OR EXEMPLARY DAMAGES OR LOST PROFITS FROM ANY BREACH OF THIS LIMITED WARRANTY OR OTHERWISE.
