SCOUT 2 LIFT GRAPH
POOL
DECK
0
10
SEAT ATTACHED AT LOWEST POSITION
CURB CAN
ONLY
BE CLEARED WITH
PULLOUT LEGREST
11
20
30
9889 GARRYMORE LANE
MISSOULA, MT 59808
FAX (406) 549-2602
MINIMUM SETBACK = 19"
MAXIMUM SETBACK = 35"
DRAW YOUR PROFILE ON
THE GRAPH USING THE
CENTER OF THE ANCHOR
AS YOUR START POINT.
ALL GRAPH LINES ARE IN
1" INCREMENTS.
0
35
(406) 549-0769
PRODUCT:
PRODUCT:
SCOUT 2
PART #:
F-800SC2
SCALE:
SCALE:
DATE:
DATE:
1:12
12/23/2016
REVISION:
REVISION:
DRAWN BY:
DRAWN BY:
KR
A
