Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the figures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notified within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may affect the safety of the user.
Copyright © 2018 Aqua Creek Products All Rights Reserved
LEAVE THIS MANUAL WITH LIFT OWNER
Lift safety can only be ensured if the lift is installed and
operated according to these instructions.
• NEVER permit children to play on or around the lift
• Do not allow children to use the lift without adult
supervision
• NEVER apply direct water pressure to the electronics
• NEVER use the lift with a dry pool
READ CAREFULLY
Scout Series
Wood Deck
Anchor
PART #: F-842SWDA
MANDATORY
Read and follow all instructions.
1
Revised 10/18/18
Advertisement
Related Manuals for Aqua Creek Products Scout Series
Summary of Contents for Aqua Creek Products Scout Series
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notified within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user. Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 10/18/18...
-
Page 2: Parts List
3/8” stainless steel hex bolts to drill throught the joist(s) and secure with nuts and washers or 3/8” stainless steel lag bolts. Aqua Creek recommends type 316 Stainless on all individually sourced hardware if available. Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 10/18/18... -
Page 3: Installation Instructions
7. Re-insert the anchor assembly and secure in place using the 3/8” stainless steel bolts, washers and lock nuts sourced locally. 8. Bond the anchor according to local code requirements. Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 10/18/18... - Page 4 BONDING LUG ADJUST WIDTH TO FIT BETWEEN FIGURE 3 JOISTS NOTE: Product should be installed and bonded according to all local codes. Check local codes for bonding and other requirements. Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 10/18/18...
- Page 5 Make sure it doesn’t wobble as it rotates. Then the lift is ready for use. SCOUT LIFT OR SCOUT HI-LIFT 1/2" X 3" FIXING BOLT 1/2" FLAT WASHER FIXING 1.9" BRACKET POST FIXING ANCHOR FIGURE 4 Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 10/18/18...
