9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | +1-406-549-0769
www.aquacreek.com
Check entire box and inside all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical all parts be carefully inspected by the installer prior to installation to ensure no
damage occurred in transit and a damaged part is not used. If any damage occurred in transit,
Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may affect the safety of the user.
Copyright © 2017 Aqua Creek Products All Rights Reserved
375 LB. [170 kg] MAXIMUM WEIGHT CAPACITY
LEAVE THIS MANUAL WITH LIFT OWNER
Lift safety can only be ensured if the lift is installed and
operated according to these instructions.
• NEVER permit children to play on or around the lift
• Do not allow children to use the lift without adult
supervision
• NEVER apply direct water pressure to the electronics
• NEVER use the lift with a dry pool
• For safety reasons, NEVER swim alone
• NEVER manually rotate the lift
ADA COMPLIANT
READ CAREFULLY
Scout 2
Pool Lift
PART #: F-802SC2
US PATENT NUMBER: [D507,769 S]
MANDATORY
Read and follow all instructions
1
Revised 5/9/17
Advertisement
Table of Contents
Related Manuals for Aqua Creek Products Scout 2
Summary of Contents for Aqua Creek Products Scout 2
- Page 1 If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user.
-
Page 2: Table Of Contents
Scout 2 Components 1. THE SCOUT 2 LIFT MAIN ASSEMBLY 2. CONTROL ARM 3. LIFTING ARM 4. ADJUSTABLE SEAT ARM 5. FOOTREST 6. ACTUATOR 7. HANDSET 8. 24 V BATTERY Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17... - Page 3 Installation: ADA Guidelines ADA REQUIREMENTS (For Commercial Applications) The Scout 2 Lift is completely ADA Compliant when installed correctly. The installation must meet the following requirements: • Clear deck space dimensions (see FIGURE 1) • Install lift a minimum of 19 inches from the pool edge (For curved pool walls contact Aqua Creek for placement) •...
-
Page 4: Anchor Installation: Core-Drill Retro-Fit
Remove plug and clean out the holes with a wire brush. Insert an air nozzle to the bottom of the hole. Use a pump or compressed air to blow out the hole. A heat-gun may be helpful in drying out the hole. continued on page 5 Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17... - Page 5 Adjust the hole as needed. NOTE: Pool decks with pavers or thick tiles may require other anchor options. Contact Aqua Creek Products. Inject epoxy adhesive into each hole starting at the bottom until the hole is 1/3 to 1/2 full.
-
Page 6: Anchor Installation: Saw-Cut Retro-Fit
8-AWG SOLID COPPER WIRE (TO BONDING GRID) DRILLING AND EPOXYING REBAR TO EXISTING SLAB (4" MIN. EMBED W/ HILTI RE500 SD OR SIMPSON SET-XP EPOXY) IS RECOMMENDED TO RESIST DIFFERENTIAL MOVEMENTS FIGURE B Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17... -
Page 7: Scout 2 Lift Assembly Instructions
NOTE: Be careful not to over-tighten bolts. Over-tightening can cause damage and around the wrong way. Make sure the end marked “B” is towards the mast, as shown. compromise the safety of your lift. Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17... - Page 8 FIGURE F cable. The lift will only operate when the battery is connected properly. WHEN LIFT IS NOT IN SERVICE, STORE BATTERY ON THE CHARGER! PHOTO 4 PHOTO 5 Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17...
- Page 9 5/16" X 3-1/2" HEX BOLT 5/16" NYLOCK 5/16" FLAT 5/16" FLAT WASHER WASHER CHAIR ARM ADJUSTMENT HOLES IN 4" INCREMENTS (16" ADJ. RANGE) CHAIR ADJUSTED TO LOWEST POSITION FIGURE G Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17...
- Page 10 Note: If you feel your lift is malfunctioning due to a faulty battery or connections, contact Aqua Creek Products for a testing kit. Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17...
-
Page 11: 24V Battery
24V BATTERY BATTERY CONNECTOR MALE CONNECTOR BATTERY TEST CABLE INSERT TEST PROBES TO CHECK VOLTAGE Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17... -
Page 12: Proper Care Of Pool & Spa Lifts
3M Scotch Brite™ pad. Use white epoxy paint to touch up the finish. Apply wax to protect when dry. For service and/or replacement parts contact Aqua Creek direct at Toll free: (888) 687-3552 Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17... -
Page 13: Scout 2 Parts List
1/4-20 X 1 HEX BOLT BUSHING WF 1/4 1/4 FLAT WASHER BATTERY/CONTROL BOX F-BCC-11 COVER NN 1/4 1/4-20 NYLOCK NUT BS 3/8 X 1 1/4 3/8 X 1 1/4 SHOULDER 18-8 BOLT Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17... -
Page 14: Seat Assembly Parts List
PIN, COTTERLESS PIN, 18-8 SS, 1/4 X 3 3/4 LANYARD LANYARD, FOR FOOTREST PIN, SS SPH 10 X 3/4 SCREW, 316 SS, #10 X 3/4”, PHSMS F-38SB SEATBELT, 2” WIDE W/ VELCRO Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 5/9/17... - Page 15 SHALL AQUA CREEK’S LIABILITY EXCEED THE ENTIRE AMOUNT PAID TO AQUA CREEK BY THE ORIGINAL PURCHASER FOR THE FAILED OR DEFECTIVE PRODUCT. IN NO EVENT SHALL AQUA CREEK PRODUCTS, LLC BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, INDIRECT, PUNITIVE OR EXEMPLARY DAMAGES OR LOST PROFITS FROM ANY BREACH OF THIS LIMITED WARRANTY OR OTHERWISE.
- Page 16 *For Revolution Only TRANSPORT CARTS F-814SCTC Scout 2 SOLAR CHARGERS F-714RTC Revolution F-045SCH Scout 2 | Revolution | Titan Elite | Ultra UPGRADE PACKS F-800SCAP Scout 2 w/ Linak UPGRADE PACKS INCLUDE** F-800SCAPV Scout 2 w/ Vito Lift Cover Extra Battery...
