Revolution Spa
Lift Manual
9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | +1-406-549-0769
www.aquacreek.com
PART #: F-702RLNA-SPA-02
US PATENT NUMBER: [D507,769 S]
500 LB. [227 kg] MAXIMUM WEIGHT CAPACITY
FOR INDOOR OR OUTDOOR USE
MANDATORY
LEAVE THIS MANUAL WITH LIFT OWNER
ADA COMPLIANT
READ CAREFULLY
Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may affect the safety of the user.
1
Copyright © 2018 Aqua Creek Products All Rights Reserved
Revised 11/30/18
Advertisement
Related Manuals for Aqua Creek Products F-702RLNA-SPA-02
Summary of Contents for Aqua Creek Products F-702RLNA-SPA-02
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user. Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18...
- Page 2 REDUCE THE RISK OF DROWNING! Supervise children at all times. No jumping or diving from the lift. Seat may be hot, use caution when entering. Keep covered when not in use. Inspect and clean before use. INDOOR BATTERY CHARGER: AMPERAGE = 0.65 FREQUENCY = 60 24 VOLT BATTERY AMPERAGE = 8 IP RATING = IPX5 Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18...
-
Page 3: Table Of Contents
Revolution Spa Components 1. The Revolution Spa Main Assembly 2. Control Arm 3. Lifting Arm 4. Spa Seat Arm 5. Pull-out Legrest 6. Actuator 7. Vito Handset 8. 24V Battery Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18... -
Page 4: Ada Installation Guidelines
• Installed a minimum of 16 inches from the pool wall • Deck slope no greater than 1:48 • The seat must submerge at least 18 inches into the water. The lift should be installed at a location with 42 inches - 48 inches of depth (deck to pool fl oor) • Anchor setbacks are based on straight pool/spa walls. Curved pool/spa walls will effect the anchor setback. [122cm] 48" REQUIRED CLEAR DECK [91.4cm] 36" SPACE [30.5cm] 12" [73.7cm] 29" [40.6cm] 16" WATER POOL WALL FIGURE 1 Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18... -
Page 5: Anchor Installation: New Construction
E.W., TOP & BTM. & SLEEVE #4 U BAR @ TOP 4'-3" (SEE FIGURE B) 2" DECK FIGURE B EPOXY TOP MATT 3" FIGURE A TO EXISTING SLAB 10" (4" MIN. EMBED) Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18... -
Page 6: Ada Fixing Insert Installation
7. Re-install the lift into the anchor and using the 1/2 inch bolt and washer, carefully thread into the installed anchor until snug. TO PREVENT BREAKING THE FIXING BRACKET, DO NOT OVERTIGHTEN! 1/2" X 2" HEX BOLT 1/2" FLAT MAIN ASSEMBLY WASHER POST ANCHOR DECK STEP 1 Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18... -
Page 7: Revolution Spa Assembly Instructions
SHOULDER BOLT 3/8" FLAT SHOULDER BOLT WASHER 3/8" NYLOCK NUT CONTROL 5/16" NYLOCK NUT 5/16" FLAT WASHER 3/8" NYLOCK 3/8" X 2" SHOULDER BOLT LIFTING ACTUATOR STEP 3 STEP 2 Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18... -
Page 8: Pull-Out Legrest Instructions
SEAT ASSEMBLY TO THE CHAIR ARM! MAIN ASSEMBLY STEP 5 STEP 5 3/8" X 2" SHOULDER BOLT 5/16" FLAT WASHER (3) 5/16" NYLOCK NUT (2) 5/16" X 4 1/2" HEX BOLT Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18... - Page 9 NOT PROPERLY ALIGNED. FOOTREST TUBE. With the lift completely assembled, run the lift fully out and back in 3-5 times, without weight, for the lifts “break in” cycle period. HANDSET CONTROL STEP 6 BATTERY SEAT ASSEMBLY CONTROL PULL-OUT LEGREST STEP 7 Not Seated Seated Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18...
- Page 10 PLUG FIGURE 8 DRILL 9/32" 3/4" (THIS SIDE) CHAIR SUPPORT TUBE (BOTTOM VIEW) 1" FIGURE 9 DRILL 9/32" HOLE (BOTTOM OF CHAIR SUPPORT TUBE) (SEE DRAWING TO THE RIGHT) Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18...
- Page 11 FLUSH WITH 2" SQ. TUBE FIGURE 10 The PULL-OUT LEGREST is now ready to use. However, before using, slide the legrest in and out, and put the pad up and down to make sure everything works smoothly. LEGREST STOWED PULL LEGREST OUT FLIP LEGREST UP AND PIN SLIDE FORWARD AND INSERT PIN TO LOCK IN "UP" POSITION SLOT Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18...
- Page 12 Note: the lift will not retract if the battery is not fully charged or if the control box is not working. The emergency button only overrides the remote handset. Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18...
- Page 13 Pinch Point Locations CAUTION! PINCH POINT AREAS! Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18...
- Page 14 3M Scotch Brite™ pad. Use white epoxy paint to touch up the finish. Apply wax to protect when dry. For service and/or replacement parts, contact Aqua Creek Products Toll free: (888) 687-3552 Copyright © 2018 Aqua Creek Products All Rights Reserved...
- Page 15 24 VOLT LINAK BATTERY NN 1/4 NUT, 316 SS, NYLOCK, 1/4-20 F-UBC BATTERY/CONTROL BOX COVER BOLT, 18-8 SS, 1/2 X 2 3/4 BS 1/2 X 2 3/4 18-8 SHOULDER, 3/8-16 THREAD Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18...
- Page 16 BOLT, 316 SS, 1/4-20 X 3 1/4 BHSCS NN 1/4 NUT, 316 SS, NYLOCK, 1/4”-20 SFL 12 X 3/4 SCREW, 316 SS, #12 X 3/4 FHSMS F-38SB SEAT BELT, 2” BLACK W/VELCRO Copyright © 2018 Aqua Creek Products All Rights Reserved Revised 11/30/18...
- Page 17 SHALL AQUA CREEK’S LIABILITY EXCEED THE ENTIRE AMOUNT PAID TO AQUA CREEK BY THE ORIGINAL PURCHASER FOR THE FAILED OR DEFECTIVE PRODUCT. IN NO EVENT SHALL AQUA CREEK PRODUCTS, LLC BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, INDIRECT, PUNITIVE OR EXEMPLARY DAMAGES OR LOST PROFITS FROM ANY BREACH OF THIS LIMITED WARRANTY OR OTHERWISE.
- Page 18 ROTATIONAL LIFT ACCESSORIES COVERS ACCESSORIES & OPTIONS F-450BL-C Scout 2 Lockable Cover, Blue F-019CA Cycle Attachment F-450BL-CT Scout 2 Lockable Cover, Tan F-105LAR Pull-Out Legrest F-450SSC Scout 2 Cover, Blue F-422PLH-2 Headrest (use with Solar Charger) F-423CS Chest Strap F-450SSC-T Scout 2 Cover, Tan F-38SB Seat Belt, Standard...
