Check box and all packing materials for parts. Before beginning assembly, read the instructions
and identify parts using the fi gures and parts listed in this document.
It is critical all parts be carefully inspected prior to installation. If any damage occurred in transit,
Aqua Creek must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may affect the safety of the user.
Copyright © 2016 Aqua Creek Products All Rights Reserved
400 LB. [181 kg] MAXIMUM WEIGHT CAPACITY
LEAVE THIS MANUAL WITH LIFT OWNER
Lift safety can only be ensured if installed and operated
• NEVER permit children to play on or around the lift
• Do not allow children to use the lift without adult
supervision
• NEVER apply direct water pressure to the electronics
• NEVER use the lift with a dry pool or spa
READ CAREFULLY
PART #: F-005SLU
US PATENT NUMBER: [D507,769 S]
MANDATORY
Read and follow all instructions.
according to instructions.
ADA COMPLIANT
1
Revised 1/29/16
Advertisement
Related Manuals for Aqua Creek Products SPA LIFT ULTRA
Summary of Contents for Aqua Creek Products SPA LIFT ULTRA
- Page 1 It is critical all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user. Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 1/29/16...
- Page 2 4. Hand Remote 5. Safety Belt 6. Hardware bag with anchor inserts & anti-seize (if ordered w/ anchor) NOTE: For wood deck applications refer to Wood Deck Anchor Manual (F-107UEWDA) Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 1/29/16...
- Page 3 E.W., TOP & BOTT. EPOXY TOP MATT TO EXISTING SLAB (4" MIN. EMBED, 3-SIDES) 3'-3" 4" (MIN) POOL/SPA WALL 10.75" 10.75" 3'-3" 10.75" 1" x 8" ANCHOR INSERTS 10" FIGURE 1 Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 1/29/16...
- Page 4 3/8" FLAT WASHER 3/8" NYLOCK ACTUATOR 1/2" X 3" SHOULDER BOLT 5/16" FLAT WASHER 5/16" NYLOCK 3/8" X 1 1/4" SHOULDER BOLT MAST ASSEMBLY LOWER ATTACHMENT POINT FIGURE 5 FIGURE 4 Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 1/29/16...
- Page 5 7. Attach the safety belt to the chair, as shown in FIGURE 8. 8. The Spa Lift Ultra is now assembled and ready for use! Be sure the battery is fully charged. FIGURE 9 shows completed assembly mounted on a spa deck.
- Page 6 Note: the lift will not retract if the battery is not adaqately charged or if the control box is not working. The emergency button only overrides the remote handset. Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 1/29/16...
- Page 7 Optimum operating range is between 5 degrees Celsius (40 degrees F) and 40 degrees Celsius (105 degrees F.) 5. Never drop or bump the battery pack. This may result in loose or damaged internal connections, and may damage the battery terminals. Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 1/29/16...
- Page 8 BATTERY, LINAK, 24 VOLT BOLT, 18-8 SS, 3/8 X 1 1/4 F-104JH REMOTE, 4 BUTTON BS 3/8 X 1-1/4 18-8 SHOULDER, 5/16-18 THREAD WF 3/8 WASHER, FLAT, 3/8, 316 SS Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 1/29/16...
- Page 9 PIN, COTTERLESS PIN, 18-8 SS, 1/4 X 3 3/4 LANYARD LANYARD, FOR FOOTREST PIN, SS SPH 10 X 3/4 SCREW, 316 SS, #10 X 3/4”, PHSMS F-38SB SEAT BELT, 2”, STANDARD, BLACK Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 1/29/16...
- Page 10 (ITEM # F-005SLU & F-006SLE) Aqua Creek Products, LLC (a.k.a. Aqua Creek) also warrants to the original end user purchaser that products manufactured by Aqua Creek, when properly installed in accordance with assembly and installation instructions, and properly used and maintained, shall be free from...
- Page 11 Sling Seat Assembly* F-450SLEC Spa Lift Elite *For Revolution & Titan Only F-450SLECS Spa Lift Elite (for use with solar charger) F-450SLUC Spa Lift Ultra TRANSPORT CARTS F-450SLUCS Spa Lift Ultra (for use with solar charger) F-428HT Ranger/Pro Pool F-914STC...
