Maintenance

Lubricate Grease Fittings

Note: See chart for service intervals.
1. Stop engine, wait for all moving parts to stop, and
remove key. Engage parking brake.
2. Lubricate fittings with NGLI grade #2
multi-purpose gun grease.
Refer to the following chart for fitting locations
and lubrication schedule.
Lubrication Chart
Fitting Initial
Locations Pumps
1–2
1. Idler
Bushings
1–2
2. Door
Handle
Number of Service
Places Interval
1 25 Hours
1
25 Hours

Check Condition of Belt

Service Interval: Every 50 hours
1. Stop engine, wait for all moving parts to stop, and
remove key. Engage parking brake.
2. Inspect the belt for damage or wear. Replace belt
with one of the following:
Deck
60 inch Lazer Z, XS, XP
SN 599,999 and Lower
and All Lazer AS
72 inch All SN 599,999
and Lower
60 inch Triton and Series 5 109-1242
66 inch Triton
72 inch Triton and Series 5 109-1244
18
Part No.
103-0866
103-0867
103-0867
