Torque Requirements; Product Overview - Exmark ULTRAVAC QUICK DUMP SYSTEM Operator's Manual

66 inch Deck-All
Liquid-Cooled
72 inch Deck-SN 599,999
and Lower
72 inch Deck-SN
600,000–789,999
Air-Cooled
72 inch Deck-SN 600,000
and Higher Liquid-Cooled

Torque Requirements

Bolt Location
Impeller Spindle Bottom
Nut
Impeller Spindle Top Nut
w/UltraVac QDS
278 lb (126 kg)
341 lb (155 kg)
260 lb (118 kg)
278 lb (126 kg)
Torque
55-60 ft-lb (75-81 N-m)
75-80 ft-lb (102-108 N-m)

Product Overview

1. Hood
2. Weight
3. Blower
11
Product Overview
Figure 4
4. Tube
5. Door
