- Page 1 INSTALLATION MANUAL C L U B 1 4 0 P L E A S E L E AV E T H E S E I N ST R U CT I O N S B E H I N D W I T H T H E D E V I C E...
-
Page 3: Table Of Contents
10.1 Maintenance in the combustion chamber 10.2 Cleaning the glass 11 PLACING THE DECORATION MATERIAL 12 LED-LIGHTING 12.1 Function of the handheld transmitter for the Club Series 12.2 LED ports 13 USER INSTRUCTION 13.1 Hand over to the customer 13.2 Maintenance instructions for the installer 13.3 Anti-reflective glass... -
Page 4: Ce Statement
This declaration loses its validity when changes to the device are Parts are only to be changed with original parts by the original made without the written permission by Element4. You can ask manufacturer. for a copy of the test certificates of all models via our general e-mail adress, which is found on the back of this manual. -
Page 5: Warranty
In case the installer is not able to fix the problem himself, a request can be made to Element4 to do it for him, as long as the service can be done within the borders of the Benelux. -
Page 6: Remote Control With Full Electronic Ignition
4 REMOTE CONTROL WITH FULL ELECTRONIC IGNITION 4.1) or the The unit is operated using a remote control (Fig. Element4 Puck, connected to a receiver (Fig. 4.2). The receiver is powered by 4 pen lite (type AA) batteries or a 6V adapter;... -
Page 7: Installation Preparation And - Instruction
85 C. Use the ventilation grate (CVRE4) and service hatch 5.4 Requirements flue and wall terminals (BDLE4) by Element4. See the measurements in APPENDIX I More on chimney construction in The European CE-marking for the device is only applicable to THE NEXT CHAPTER. -
Page 8: Fire Safe Installation
I N STA L L AT I O N M A N UA L 6 FIRE SAFE INSTALLATION To install a gas fireplace as safely as possible, several installation preparations need to be made. This overview can be used to assure the fire safety of a conversion of a fireplace. -
Page 9: Assembly Regulations With Flammable Materials
I N STA L L AT I O N M A N UA L 6.3 Assembly regulations with flammable materials (Figure 6.3 and 6.4) Load-bearing walls and ceilings must be covered in a protective fire resistant plate. Never use flammable materials around the fireplace or cove. The minimal distance between the device and non-flammable materials must be at 50 mm to ensure a convection air flow. -
Page 10: Attention Points Gas Flue
I N STA L L AT I O N M A N UA L 7 ATTENTION POINTS GAS FLUE 8 INSTALLATION CHECK AND FIRST USAGE 8.1 Renovation/new construction To guarantee the fire safety regarding you flue gas configuration a casing is necessary. For this case non-combustible materials should be used. -
Page 11: Electrical Circuit
I N STA L L AT I O N M A N UA L 9 ELECTRICAL CIRCUIT Figure 9.1 The Club Series offers the posibilty to change the colour of the shows a simplified connection circuit for the fireplace. Every fireplace is provided with a main adapter. The Element4 fire bed, next to the standard options already available on the ProControl app. -
Page 12: Maintenance Instruction
I N STA L L AT I O N M A N UA L 10 MAINTENANCE INSTRUCTION This part of the manual focuses on maintenance. To ensure the optimal flame picture of your device, an annual maintenance by a competent company or installer is prescribed. 10.1 Maintenance in the combustion chamber Please note: The following steps are only applicable to the Club 140 Front,... - Page 13 I N STA L L AT I O N M A N UA L Figure 10.2 - Remove side trims Figure 10.5 - Using the suction cup Figure 10.3 - Remove Lower Trims Figure 10.6 - Removing the suction cup Figure 10.4 - Removing Glass Cords Figure 10.7 - Removing side windows (when necessary)
-
Page 14: Cleaning The Glass
• Use cleaning supplies qualified by Element4. • When you clean your Anti-Reflective glass, make sure you use this with the special Element4 cleaner, which is available only via Element4. Figure 10.8 - Lucius- & Tenore 140 • Use only a microfibre cloth. Other materials such as kitchen towels, steel wool etcetera can cause scratches or damage the coating on the glass. - Page 15 I N STA L L AT I O N M A N UA L Figure 10.9 - Remove side trims Figure 10.12 - Put on the suction cup Figure 10.10 - Remove bottom trim Figure 10.13 - Remove glass Figure 10.11 - Remove glass clamps...
-
Page 16: Placing The Decoration Material
I N STA L L AT I O N M A N UA L 11 PLACING THE DECORATION MATERIAL 12 LED-LIGHTING Every fireplace in the Element4 Club Series is equipped with a As already briefly mentioned in CHAPTER 9 , the Element 4 Club very thin ribbon burner for a maximum light effect. -
Page 17: User Instruction
In order not to damage the coating layers, the use of hard (sanding) sponges, abrasives and cleaning agents with ammonia is prohibited. Only use a neutral cleaning product (neither acidic nor alkaline), such as Element4 window cleaner... -
Page 18: A First Aid For Malfunction
A P P E N D I C E S A FIRST AID FOR MALFUNCTION Below you will find an overview of the possible cause and solution in the event of a failure. Problem Possible Cause Solution No transmission 1 Batteries in the receiver empty Replace the batteries (4x 1.5V AA) (motor will not 2 Batteries hand remote empty... - Page 19 A P P E N D I C E S 4,5 mV 4,5 mV Figure A-1: Bend pin Figure A-4: Testpoint A Figure A-5: interrupter Figure A-2: Antenna Figure A-6: Wiring receiver Figure A-7: Pilot set Figure A-3: Torx screw...
- Page 20 A P P E N D I C E S Problem Possible Cause Solution The pilot light goes 1 Insufficient voltage across the thermocouple or Place the measuring pins of the multimeter on the ground and on but goes out too much resistance in the thermocouple circuit black cable of the breaker.
- Page 21 A P P E N D I C E S Figure A.8: Second thermocouple Figure A.9: Button A on “On” Figure A.11: “Double plus”-button on the remote Figure A.13: SI-port Figure A.10: RESET-button Figure A.11: Aux-position receiver Figure A.14: Domotica system...
-
Page 22: B Errors Codes Procontrol App
A P P E N D I C E S B ERRORS CODES PROCONTROL APP B.1 Messages shown in app Error Message in App Description Possible cause code Contact Service. • 5 sec. beep from Receiver • Microswitch not making contact with cam on motor knob •... -
Page 23: Messages Shown In Remote
A P P E N D I C E S Error Message in App Description Possible cause code Contact Service. • Fire is not responding • Receiver or Wi-Fi Box malfunction • No electronic control of fire • Connection cable from Receiver to Wi-Fi Box defective Check Wi-Fi •... -
Page 24: C Faults And Error Codes In The Remote
A P P E N D I C E S C FAULTS AND ERROR CODES IN THE REMOTE This appendix can be consulted when error messages occur in the application for smartphone and tablet. C.1 F41 error This message will appear if there is no or bad Wi-Fi reception, this can be between app and router or Wi-Fi box and router By closing the App and opening it again, this is solved in most cases. -
Page 25: D Location Terminal
A P P E N D I C E S D LOCATION TERMINAL D.1 Terminal location with vertical exhaust (C11) D.2 Terminal location with Horizontal exhaust (C31) Distance Exhaust 1,2 of 3 Position terminal dist. (mm) At the same roof level >... -
Page 26: E General Rules For Flue Gas Extraction
A P P E N D I C E S E GENERAL RULES FOR FLUE GAS EXTRACTION E.1 Power-Fan For flue configurations that do not function on natural draft, the PowerFan can be used. For extensive installation instructions and the operation of the PowerFan we refer to the manual of the PowerFan. -
Page 27: F Calculation Table Flue Gas Reduction
A P P E N D I C E S F CALCULATION TABLE FLUE GAS REDUCTION The calculation table shows when you need to place a flue gas ristrictor Result Action No ristrictor required √ Position the resitrictor No good operation guaranteed * F.1 Horizontal terminal flue diameter 200/130 F.2 Vertical terminal flue diameter 200/130 For a vertical terminal the minimal starting length is 0,5 meter... -
Page 28: G Technical Data
A P P E N D I C E S G TECHNICAL DATA The dataplate specifies for which type of gas, gas pressure and for which country this appliance is intended. The nameplate is attached to a chain. It must remain attached to the chain. Note: Check whether the appliance is suitable for the gas type and gas pressure on site. -
Page 29: H Ecodesign
A P P E N D I C E S H ECODESIGN Since 1 January 2018 every fireplace has been provided with an eco-label which is always supplied with the fireplace. The ecolabel shows which category the fireplace belongs to. H.1 Ecolabels The ecolabels for the different types of gas are indicated below, respectively G20, G25 and G30. -
Page 30: I Dimensional Drawings
A P P E N D I C E S I DIMENSIONAL DRAWINGS On this page and the following ones you will find dimensional drawings of the 140 models and accessories with some of the important dimensions that you have to take into account when installing and installing your fireplace. - Page 31 A P P E N D I C E S I.2 - Technical drawing of Club 140 F...
- Page 32 A P P E N D I C E S Figure I.3 - Technical drawing of Club 140 C...
- Page 33 A P P E N D I C E S I.4 - Technical drawing of the Club 140 3S...
- Page 34 A P P E N D I C E S Figure I.5 - Technical drawing of Club 140 RD...
- Page 35 A P P E N D I C E S I.6 - Technical drawing of the Club 140 T...
- Page 36 E L E M E N T 4 B .V. Paxtonstraat 23 8013 RP Zwolle The Netherlands Info@element4.nl www.element4fires.com R E L E A S E DAT E | 1 2 / 0 6 / 1 9...
