Model
EPB 8-1800-10S
EPB 8-1800-4Q
EPB 14-900-10S
EPB14-900-4Q
EPB 17-700-10S
EPB 17-700-4Q
Download the latest version of this document at
http://www.desouttertools.com/info/6159929400_EN
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
Cordless Pistol Nutrunner
Product Instructions
Part number
6151659030
6151658990
6151659770
6151659780
6151659010
6151659050
WARNING
Printed Matter No. 6159929400_EN
Issue No.
01
Date
06/2020
Page
1 / 24
Advertisement
Table of Contents
Related Manuals for Desoutter EPB 8-1800-10S
Summary of Contents for Desoutter EPB 8-1800-10S
- Page 1 Printed Matter No. 6159929400_EN Issue No. Date 06/2020 Page 1 / 24 Cordless Pistol Nutrunner Product Instructions Model Part number EPB 8-1800-10S 6151659030 EPB 8-1800-4Q 6151658990 EPB 14-900-10S 6151659770 EPB14-900-4Q 6151659780 EPB 17-700-10S 6151659010 EPB 17-700-4Q 6151659050 Download the latest version of this document at http://www.desouttertools.com/info/6159929400_EN...
-
Page 2: Table Of Contents
Table of Contents Product Information .......................... 3 General Information......................... 3 Warranty.......................... 3 Website .......................... 3 Information about spare parts .................... 3 Dimensions .......................... 4 CAD files .......................... 4 Overview ............................ 4 General overview ......................... 4 Product description ...................... 5 Technical data........................ 5 Accessories.......................... 7 Installation.............................. 8 Installation Instructions........................ 8 Inserting the battery pack..................... 8 How to connect the tool to CVIMONITOR................ 8 Mounting the side handle ..................... 8 How to install optional accessories .................. 9 Operation.............................. 10... -
Page 3: Product Information
• The product warranty relies on the correct use, maintenance, and repair of the tool and its component parts. • Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Desoutter or their Certified Service Partners during the warranty period is not covered by the warranty. -
Page 4: Dimensions
Overview General overview EPB tools are cordless pistol nutrunners. They are hand-held by the operator and powered by a Desoutter battery pack. On delivery, the tool display is protected by a password. Tools are delivered with 1 Pset. The target torque is configurable from the tool display. -
Page 5: Product Description
Product Information Product description Output drive Front light Trigger Reverse button Reporting LEDs Display Programming buttons Technical data Voltage (V) 18 V or 36 V Output drive Model Type EPBx 8-1800-10S Sq. 3/8” EPBx 8-1800-4Q Hex. 1/4" F EPBx 14-900-10S Sq. - Page 6 Product Information Model Min. / Nominal / Max. EPBx 14-900-4Q 4 / 12 / 14 EPBx 17-700-10S 7 / 15 / 17 EPBx 17-700-4Q 7 / 15 / 17 EPBx stands for EPB/EPBA. Torque range (ft.lb) Model Min. / Nominal / Max. EPBx 8-1800-10S 0.34 / 1.57 / 1.80 EPBx 8-1800-4Q...
-
Page 7: Accessories
Product Information Usable in Pollution degree 2 environment Indoor use only Accessories Optional accessories eDOCK 6158119760 Side handle 6153970160 Tracker 6158132600 Required accessories Battery pack 18 V 2.5 Ah 6158132660 Battery pack 36 V 2.5 Ah 6158132670 Battery pack charger 6158132700 06/2020 7 / 24... -
Page 8: Installation
Installation Installation Installation Instructions Inserting the battery pack Insert the battery pack in front or behind the tool until a locking sound can be clearly heard. There is no ON/OFF switch: the tool is ready to operate as soon as a battery pack is mounted. When the tool is powered on, tool LEDs are blinking. -
Page 9: How To Install Optional Accessories
Installation How to install optional accessories Refer to the user manual dedicated to the accessory available at https://www.desouttertools.com/resource-centre. 06/2020 9 / 24... -
Page 10: Operation
Operation Operation Configuration Instructions How to configure the tool Icons and buttons The password is enabled. The password is disabled. Press the button "Validate/Run reverse". Press the right button. Press the left button. "Validate/Run reverse" button Right button Left button Validate Save Quit... - Page 11 Operation The procedure is the same to disable the Maintenance password. How to set up new passwords To set new passwords, current passwords must be disabled and the green padlock displayed. Go to the main screen. Press this button during 2 seconds. Press this button to reach Configuration.
- Page 12 Operation Go to Torque unit, use the buttons to select the torque unit and validate. How to set up the Pset Check that the Pset password is disabled. The green padlock is displayed on the top line. Go to the main screen. Press this button during 2 seconds.
-
Page 13: Operating Instructions
Operation Item Parameter Description Rundown speed Speed applied from the start to "Down- shift torque". Downshift torque Torque value where the speed moves from "Rundown speed" to "Downshift speed". Downshift speed Speed applied from "Downshift torque" to the motor stop. Operating Instructions How to use the tool Starting the tool... - Page 14 Operation Max. angle Examples: - Both torque and angle within tolerances will lead to a green LED reporting. - Torque within tolerances and angle below tolerances will lead to red + yellow status (red LED). For tools running in severe applications, it may happen that reports are null when the battery is low. Reporting LEDs Green Yellow...
-
Page 15: Results Monitoring
Operation Press this button during 2 seconds. Go to Ergostop. Use the buttons to enable or disable the function, save and validate. How to wake up EPB tools The tool display switches off automatically after 2 minutes of inactivity. Press the trigger or move the tool. The tool powers off after 30 minutes of inactivity. -
Page 16: Service
Service Service Firmware version on tool display The firmware version of the tool is displayed in the menu "Maintenance/Tool". FX.YY.ZZ. Tool information from tool display Go to "Maintenance/Tool" menu to get the following information: Total counter Number of tightenings since the manufacturing of the tool. Battery The current voltage value is displayed. -
Page 17: Instructions For Transducerized Tools
Service Right hand thread When reassembling: Apply the recommended glue. Tighten to the required torque. Lubricate with the required grease or oil. Do not apply too much grease on gears or bearings; a thin coat shall be sufficient. Instructions for transducerized tools •... -
Page 18: Calibration Via Tool Display
This function is set in the "Maintenance" menu. Enter the Maintenance password in the "Configuration" menu. Insert a torque transducer in line with the tool and connect it to any measuring unit from the Desoutter range. Go to "Maintenance/Calibration". Select the number of tightenings required to execute the calibration and press OK. -
Page 19: Motor Align
It is mandatory to calibrate the tool equipped with the fixed accessory before use. Upgrading tool firmware Click this icon. Click Upgrade tool firmware. Contact your Desoutter representative to get the last firmware version. Follow the instructions on screen. 06/2020 19 / 24... -
Page 20: Troubleshooting
1- The tool tightening counter has been reached. I038 Tool logs 1- Unexpected tool software exception. 2- Log file has been generated by the tool. 3- Contact your Desoutter representative for support. I046 Abnormal battery current 1- Abnormal battery current consumption. Check the Pset settings. - Page 21 2- Check the tool cable is not damaged. W212 Result not stored 1- It is not possible to store the tightening result in the system. 2- Contact your Desoutter representative for support. W216 Current high 1- Maximum current exceeded. 2- Contact your Desoutter representative for support.
- Page 22 Procedure E223 Drive init error 1- Software failure. 2- Restart the system. 3- If the problem occurs again, contact your Desoutter representative for support. E227 Motor stalled 1- Motor stalled (could be missing phase, wrong motor tune or power electronics failure) 2- Try once again.
- Page 24 Original instructions Founded in 1914 and headquartered in France, Desoutter Industrial Tools is a global leader in electric and pneumatic assembly tools serving a wide range of assembly and manufacturing operations, including Aerospace, Automotive, Light and Heavy Vehicles, Off-Road, General Industry.
