  • Page 1 Tests carried out on drives This documentation pertains to SL150 luftgekühlt F03 F70 F98 F79 F76 Reference Manual Medium-Voltage Drive SINAMICS SL150 Type 6SL3860 Edition 02/2019 www.siemens.com/drives...
  • Page 2 14.02.2019 14:25 V8.00...
  • Page 3 Introduction General scope of services Tests Medium-Voltage Drive SINAMICS SL150 Type 6SL3860 Reference Manual This documentation pertains to SL150 luftgekühlt F03 F70 F98 F79 F76 Edition 02/2019...
  • Page 4 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 5: Table Of Contents

    Current zero signal.........................28 Cooling system test........................29 3.3.1 Air flow direction........................29 3.3.2 Air pressure monitoring ......................29 Insulation test .........................30 3.4.1 High-voltage test ........................30 3.4.2 Measuring the insulation resistance..................31 Index................................33 SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...
  • Page 6 Table of contents SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 7: Introduction

    ● Tests that are offered as standard Note If the scope of testing and inspection cannot fulfill all customer requirements, please consult your Siemens sales advisor at head office. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...
  • Page 8 Introduction SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 9: General Scope Of Services

    5. Preparation of test documentation for the customer. The test documentation is created before or after the customer leaves depending on the scope of testing and the time schedule. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...
  • Page 10 PD LD scope of supply. This also applies to components ordered from other Siemens' Groups. The technical data for these components is required at the latest eight weeks before the start of the acceptance test, e.g.: ●...

  • Page 11: Routine Test

    General scope of services 2.1 Routine test Routine test During production, the drive is subject to an internal routine test. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 12: Visual Inspection

    ● Housing degree of protection ● Electrical cabinet components ● Cable installation ● Cable markings ● Setting values of circuit breakers, if used ● Dimensions See also Visual inspection (Page 18) SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 13: Function Tests

    Siemens directives within the scope of quality assurance. The function tests are performed and documented in the Siemens test field by internal test field personnel. For the function test, the drive is in the test mode with restricted monitoring functions.

  • Page 14: Insulation Test

    3.2 certificate. See also Insulation test (Page 30) The insulation test is performed on a separate acceptance day prior to the function test. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 15: Interface Test

    ● Additional interfaces The test is confirmed in a 3.1 certificate – or in the case that the customer has ordered the acceptance test, in a 3.2 certificate. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...
  • Page 16 General scope of services 2.5 Interface test SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 17: Tests

    Tests The tests that have been expressly ordered for the drive with serial number 12345670001001 are listed in the following. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 18: Visual Inspection

    The test together with the customer – or his representative – is carried out with the drive installed and labeled. The results of all of the tests are documented in the acceptance report. The SINAMICS SL150 drive consists of the following components: ● Power section ●...

  • Page 19: Electrical Cabinet Components

    Cable installation Fundamentals Visual and mechanical checks are made to ensure that cables and conductors have been installed correctly and are connected correctly according to the circuit diagram. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 20: Cable Markings

    Test procedure 1. The customer selects circuit breakers by random sampling. 2. The circuit breaker settings are visually checked against what is specified in the circuit diagram. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 21: Dimensions

    3.1.9 Clamping pressure on the power semiconductor stack in the power section Fundamentals The clamping pressure on the power semiconductor stack is tested with a preclamping gage. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...
  • Page 22 1. The preclamping gage is applied to the measurement position and removed again. Result The test is passed if the preclamping gage can be removed again easily. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 23: Function Test

    3. The value of the synchronization voltage is read off from the test station computer and compared with the applied voltage. Result The test is passed if the voltage values match. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 24: Inputs And Outputs Of The Tm Modules In The Control Cabinet

    The doors of the drive power section are monitored using limit switches. This monitoring function ensures that when the doors are open, the drive cannot be switched on. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 25: Door Interlocking System In The Power Section

    The test is passed if the door interlocking system functions as described. 3.2.7 Message "Ground fault monitoring" Fundamentals The test reveals whether a message is displayed on the test station computer when a ground fault occurs. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 26: Message "Disconnector Cabinet Door

    This simulates a failure of actual value acquisition. The drive switches itself off. A fault is displayed on the test station computer. Result The test is passed if the drive responds as described. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 27: Operation At Rated Voltage

    3. The output current and output voltage are measured at the output of the power semiconductor module. Result The test is passed if the defined values are measured at the output of the power semiconductor module. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 28: Current Zero Signal

    The progression of the current zero signal is displayed on the test station computer. Result The test is passed if the current gaps are symmetrically distributed over the current zero signal. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 29: Cooling System Test

    3. One of the fans is switched off. This simulates fan failure. A message is displayed on the test station computer. Result The test is passed if the drive responds as described. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 30: Insulation Test

    5. The test is repeated with 80% test voltage. Result The test is passed if the test instrument is not switched off (tripped) during the test as a result of flashover. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 31: Measuring The Insulation Resistance

    4. The circuits are tested with respect to one another and with respect to the PE protective conductor at the electrical cabinet. Result The test is passed if the insulation resistances lie within the tolerance specified by the standard. SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...
  • Page 32 Tests 3.4 Insulation test SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...

  • Page 33: Index

    Cable installation, 19 Cable markings, 20 Dimensions, 21 Electrical cabinet components, 19 Housing degree of protection, 18 Rating plate, 18 Setting values of circuit breakers, if used, 20 SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...
  • Page 34 Index SINAMICS SL150 6SL3860 F03 F70 F98 F79 F76 Reference Manual Rev.201902141425 SL150 luftgekühlt...
  • Page 36 8888888888 000088 01 EN 01 Further Information www.siemens.com/drives Siemens AG Process Industries and Drives Postfach 48 48 90026 NÜRNBERG GERMANY *888888888800008801EN01* 888888888800008801EN01...
  • Page 37 Process Industries and Drives Department PD LD P MF-NMA EN Siemens AG, PD LD P MF-NMA EN, Postfach 47 43, 90025 Nürnberg Tel. +49 (911) 433-6422 +49 (911) 433-6921 Email motoren.doku.aud@internal.siemens.co Our ref. 8888888888000088 Date 14.02.2019 Documentation for 6SL3860 Your order no. - 000010...
  • Page 39 Spine label for binder 50 mm (120 g/m2) SINAMICS SL150 6SL3860 SL150 luftgekühlt F03 F70 F98 F79 F76 Tests carried out on drives Spine label for binder 162 mm (120 g/m2) SINAMICS SL150 6SL3860 SL150 luftgekühlt F03 F70 F98 F79 F76 Tests carried out on drives...
