Summary of Contents for Leggett & Platt Raven K-120
- Page 1 owners manual Raven ™ K-120 LPAdjustableBases.com...
-
Page 3: Table Of Contents
CONTENTS Advisory ........................4 Acoustics ........................6 Installation ......................... 7 Remote Control Function .................... 11 Remote Control Programming ..................12 Troubleshooting ......................14 Accessories ....................... 15 Warranty ........................16 If adjustable base does not operate or if parts are missing, call: (800) 888-3078... -
Page 4: Advisory
ADVISORY IMPORTANT INFORMATION READ THE FOLLOWING INFORMATION CAREFULLY BEFORE USING THIS PRODUCT READ ALL INSTRUCTIONS BEFORE USING PRODUCT RATINGS The base lift motors are not designed for continuous use. Reliable operation and full life expectancy will be realized as long as the lift motors do not operate any more than two (2) minutes over a twenty (20) minute period, or approximately 10% duty cycle. - Page 5 ADVISORY IMPORTANT INFORMATION READ THE FOLLOWING INFORMATION CAREFULLY BEFORE USING THIS PRODUCT SMALL CHILDREN / PETS WARNING FCC COMPLIANCE After the base is unboxed, immediately dispose of The equipment has been tested and found to packaging material as it can smother small children comply with the limits for a Class B digital device, and pets.
-
Page 6: Acoustics
ACOUSTICS LIFTING/LOWERING MECHANISMS LOCATION ENVIRONMENT The lift/lower feature will emit a minimal humming The level of sound experienced during operation sound during operation. This is normal. is directly related to the location environment. For example, when a base is located on a hardwood floor During operation, the lift arm wheels make contact with the massage feature in operation, a vibrating with the platform support of the base. -
Page 7: Installation
INSTALLATION For installation and setup, complete the numbered procedure indicated below and on the following pages: STEP 1 Before discarding any packing materials, check the base shipping carton and verify the following items are included: WARRANTY ACTIVATION CARD (split sizes only) OWNERS MANUAL QUICK SETUP GUIDE MATTRESS... - Page 8 INSTALLATION STEP 2 READ ALL INSTRUCTIONS BEFORE USING Uncoil the main power cord and extend it out head end of base, then remove the hardware box from WARNING WARNING shipping container. Cut the zip-tie and remove the mattress retainer. POWER CORDS MUST NOT INTERFERE STEP 3 WITH ANY ADJUSTABLE BASE Install (4) legs into the base frame.
- Page 9 INSTALLATION STEP 6 Plug electrical power cord into a working, grounded electrical outlet. Note: An electrical surge protection device is recommended (not included). STEP 7 Install (2) AAA batteries (included) in remote control. Briefly activate all functions of the base with the remote control to verify all features are in working order.
- Page 10 INSTALLATION STEP 9 Install mattress retainers at the foot end of the adjustable base as follows: a. Locate grommeted holes at foot of base (FIGURE 3). b. Place mattress retainer ends into grommeted holes in top surface of adjustable base (FIGURE 3). Press down until horizontal retainer section is flush against base.
-
Page 11: Remote Control Function
REMOTE CONTROL FUNCTION HEAD DOWN BUTTON HEAD UP BUTTON Press and hold to raise the Press and hold to lower the head section. head section. HEAD/FOOT UP BUTTON HEAD/FOOT DOWN BUTTON Press and hold to raise the head Press and hold to lower the head and foot sections simultaneously. -
Page 12: Remote Control Programming
REMOTE CONTROL PROGRAMMING (1 remote control - 1 base) Program One Remote to Operate One Base - perform the following numbered procedure. STEP 1 Plug the base into working, grounded electrical outlet. STEP 2 Press and hold the learn button on the control box (FIGURE 4). - Page 13 REMOTE CONTROL PROGRAMMING (1 or 2 remote controls - 2 bases) Program One Remote to Operate Two Bases (Tandem Syncing) - perform the following numbered procedure. Note: Make sure both bases are flat before beginning procedure. BASE 1 STEP 1 Plug both adjustable bases into working, grounded REMOTE REMOTE...
-
Page 14: Troubleshooting
TROUBLESHOOTING If the adjustable base fails to operate, investigate the symptoms and possible solutions provided in the chart below: SOLUTION SYMPTOM electrical outlet. A grounded, electrical surge protection device is recommended. Test outlet by plugging in another working appliance. Remote control illuminates and appears to be operable, but will not activate base. -
Page 15: Accessories
ACCESSORIES OPTIONAL EQUIPMENT Contact customer service toll free (800-888-3078) to order the accessories indicated in the chart below. ACCESSORY DESCRIPTION CODE IMAGE Glides 4B2385 (set of 4, replaces legs) 3” Legs 4B2284 (set of 4) 4” Legs 4B1833 (set of 4) 5”... -
Page 16: Warranty
1 YEAR, 3 YEAR AND 25 YEAR LIMITED WARRANTY In this warranty: “Adjustable base” means the adjustable bed foundation sold by L&P to the dealer. The “adjustable base” does not include the mattress. “L&P” means Leggett & Platt, Incorporated. “Purchaser” and “You” both mean the consumer who is the original purchaser of this adjustable base made by L&P. - Page 17 1 YEAR, 3 YEAR AND 25 YEAR LIMITED WARRANTY Repair or replacement shall be the sole remedy of the L&P makes no other warranty whatever, express or Purchaser. There shall be no liability on the part of L&P implied, and all implied warranties of merchantability and for any special, indirect, incidental, or consequential fitness for a particular purpose are disclaimed by L&P and damages or for any other damage, claim, or loss not...
- Page 20 290-0008-b EDR13XXX 1/17 NATIONWIDE CUSTOMER SERVICE (800) 888-3078 toll free: © 2017 Leggett & Platt Adjustable Bed Group, a division of Leggett & Platt Incorporated...
Need help?
Do you have a question about the Raven K-120 and is the answer not in the manual?
Questions and answers
My bed will not operate, is there a reset button? I did everything the manual says. I t appears to have no power to operate, the remote lights up but nothing happend, I changed batterys, unplugged the unit to no avail. please help ASAP. Thanks Larry
The Leggett & Platt Raven K-120 bed does not have a specific reset button, but power issues can be resolved by unplugging the power cord, waiting 30 seconds, and plugging it back in to reset the electronic components.
