Special Tools, Solvents, and Oils List

In addition to the standard tools used to service these devices, the following
special tools should also be carried by a service technician, according to the
tool's rank. For more information on the special tools, solvents, and oils
below, see the imagePROGRAF iPF6400SE Service Manual.
Table 16 – Special Tools, Solvents and Oils List
Description
Cover switch tool
Syringe
Tube
Grease PG-
5000H
Silbon paper
Rubber gloves
Pen light
A: Each service person is expected to carry one.
B: Each five or so service persons are expected to carry one.
1 Part numbers are subject to change without notice.
H.

Installation Service Support Tools

Table 17 – Installation Service Support Tools List
Hexagonal wrench (Provided with
the printer stand)
Cut sheet paper of A3 size or larger,
or roll paper
Cutter
1 Part numbers are subject to change without notice.
imagePROGRAF iPF6400SE Service Guide
Use
For pressing down
cover switch
For draining ink
manually
For draining ink
manually
For applying to the
places specified in
the Service Manual
Use for cleaning
Use for cleaning and
to prevent from
dirtying the hands
For visibility when
locking and unlocking
the carriage.
Rank Description
Tool
For assembling the stand and
removing other fixed parts
For test printing after confirming
the printer's operation
For unpacking the printer
imagePROGRAF iPF6400SE Service Guide
1
Rank Part Number
A QY9-0103-000
A CK-0541-000
A QA2-6161-000
B FY9-6022-000
B CK-0336-000
A QC1-5547-000
B CK-0327-000
Use
Remarks
Diverted from BJ-W9000
Diverted from BJ-W9000
Diverted from W7200
Successor of MOLYCOTE
Diverted from BJ-W9000
Diverted from BJ-W9000
Diverted from BJ-W9000
Remarks
Ships with printer
Ships with printer
To cut packaging
material
February 2014
Page 15
