IntesisBox IBOX-BAC-MBRTU-100 User Manual page 21

®
IntesisBox BACnet/IP Server - Modbus RTU Master
Description BACnet object type for the signal.
Values 








Edit mode Single / Multiple Values selection.
Comments Edit using the mouse right-button-click pop-up menu
Description BACnet object instance number for the point. It can be manually entered by
the user or can be automatically assigned by LinkBoxBacnet when saving the
configuration (section 5.1.4)
Restrictions All the object instance numbers for objects of the same type must be
different
Edit mode Text edit or AutoEnumeration
Comments It is recommended to let LinkBoxBacnet assign automatically object instance
numbers for the points
Description Indicates if the signal is active or not for the integration
Values 

Edit mode Text edit or AutoEnumeration
Description Some Modbus devices use 0-based register addresses (also referred as
Jbus), while others use 1-based register addresses (also referred as
Modbus), in the Modbus communication (for 1-based devices, the register
address 100 is specified as 99 in the Modbus communication frames). Select
0-Based if your Modbus devices use 0-based address map (like PLCs), or
select 1-Based if your Modbus devices use 1-based address map.
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
AI = Analog Input.
AO = Analog Output.
AV = Analog Value.
DI = Digital Input.
DO = Digital Output.
DV = Digital Value.
MI = Multistate Input.
MO = Multistate Output.
MV = Multistate Value.
Bac.ID
Active
0: Not active
1: Active
0 / 1 based register
User's Manual r14 eng
URL http://www.intesis.com
Email info@intesis.com
tel +34 938047134
21 / 27
