IntesisBox BACnet/IP Server - Modbus RTU Master
Description Device number to which belongs the point. Referenced to the list of devices
defined in Connection Tab (Figure 5.4)
Values From 1 to 254
Edit mode Text edit or AutoEnumeration
Comments This is not the slave number configured in the Modbus device itself, it is just
the order of the device (from top to bottom) in the devices list
Description Modbus function code to be used by IntesisBox to read, to write or to
read/write the point in the slave device.
Values 0- Communication Error
1- Read digital outputs
2- Read digital inputs
3- Read analog registers
4- Read analog inputs
5- Write 1 digital output
6- Write 1 analog register
7- Write multiple digital output
8- Write multiple analog registers
Restrictions For Read only points function codes 1, 2, 3 or 4 can be used
For write only points, function codes 5, 6, 15 or 16 can be used
For read/write points, see section 5.1.3
Edit mode Single / Multiple Values selection.
Comments Consult documentation of Modbus device(s) to integrate for information about function codes
supported to read/write their internal points.
Description Modbus data format for the point.
