Configuring the ADSL interface
FortiGate-60 series and FortiGate-100A FortiOS 3.0 MR4 Install Guide
01-30004-0266-20070831
General keywords and variables applicable to the ADSL interface
You might need to configure these settings to communicate with your ISP.
Keywords and variables
padt-retry-timeout
<padt_retry_seconds>
password
<pppoe_password>
status {down | up}
username
<pppoe_username>

Example - IPOA or EOA

This example shows the settings required to use an IP address of 10.10.10.1 and
a netmask of 255.255.255.0 with IPOA using PPPoE and custom VPI and VCI
settings. This example also applies to the EOA mode if you change the mode
setting to eoa.
config system interface
edit adsl
set mode ipoa
set ip 10.10.10.1 255.255.255.0
set vpi 1
set vci 34
set mux-type llc-encaps
set connection enable
end
end
Configuring the ADSL interface using the CLI
Description
Initial PPPoE Active Discovery
Terminate (PADT) timeout in seconds.
Use this timeout to shut down the
PPPoE session if it is idle for this
number of seconds. PADT must be
supported by your ISP. Set PADT
timeout to 0 to use default.
This is available when mode is pppoe.
This is available in NAT/Route mode
only.
Enter the password to connect to the
PPPoE or PPPoA server.
This is available when mode is ppoe or
pppoa.
This is available in NAT/Route mode
only.
Start or stop the interface. If the
interface is stopped it does not accept
or send packets.
If you stop a physical interface, VLAN
interfaces associated with it also stop.
Enter the user name to connect to the
PPPoE or PPPoA server.
This is available in NAT/Route mode
when mode is set to pppoe or pppoa.
Default
1
No default.
up
(down for
VLANs)
No default.
