Configuring the FortiGate unit

Configuring the FortiGate unit

Planning the FortiGate configuration

NAT/Route mode

FortiGate-60 series and FortiGate-100A FortiOS 3.0 MR4 Install Guide
01-30004-0266-20070831
This section provides an overview of the operating modes of the FortiGate unit.
Before beginning to configure the FortiGate unit, you need to plan how to
integrate the unit into your network. Your configuration plan depends on the
operating mode you select: NAT/Route mode or Transparent mode.
This section includes the following topics:
• Planning the FortiGate configuration
• Preventing the public FortiGate interface from responding to ping requests
• NAT/Route mode installation
• Transparent mode installation
• Next Steps
Before you configure the FortiGate unit, you need to plan how to integrate the unit
into the network. Among other things, you must decide whether you want the unit
to be visible to the network, which firewall functions you want it to provide, and
how you want it to control the traffic flowing between its interfaces.
Your configuration plan depends on the operating mode you select. You can
configure the FortiGate unit in one of two modes: NAT/Route mode (the default)
or Transparent mode.
You can also configure the FortiGate unit and the network it protects using the
default settings.
In NAT/Route mode, the FortiGate unit is visible to the network. Like a router, all
its interfaces are on different subnets. The following interfaces are available in
NAT/Route mode:
Table 6: NAT/Route mode network segments
FortiGate Unit Internal Interface External
FortiGate-60 Internal
FortiGate-60M
FortiGate-60ADSL
FortiGate-60B
FortiWiFi-60 Internal
FortiWiFi-60B
FortiGate-100A Internal
Planning the FortiGate configuration
Other
Interface
WAN1 DMZ
WAN2
WAN1 DMZ
WAN2 WLAN
WAN1 DMZ1
WAN2 DMZ2
29
