FortiGate-60 series and FortiGate-100A FortiOS 3.0 MR4 Install Guide
01-30004-0266-20070831
For this procedure, you connect to the CLI using the RJ-45 to DB-9 serial
cable/console port. This procedure temporarily installs a new firmware image
using your current configuration.
For this procedure you install a TFTP server that you can connect to from the
FortiGate internal interface. The TFTP server should be on the same subnet as
the internal interface.
To test a new firmware image
Connect to the CLI using a RJ-45 to DB-9 serial cable/console port.
Make sure the TFTP server is running.
Copy the new firmware image file to the root directory of the TFTP server.
Make sure the internal interface is connected to the same network as the TFTP
server.
Use the following command to ping the computer running the TFTP server. For
example, if the TFTP server's IP address is 192.168.1.168:
execute ping 192.168.1.168
Enter the following command to restart the FortiGate unit:
execute reboot
As the FortiGate unit reboots, press any key to interrupt the system startup.
As the FortiGate unit starts, a series of system startup messages are displayed.
When one of the following messages appears:
• FortiGate unit running v2.x BIOS
Press Any Key To Download Boot Image.
...
• FortiGate unit running v3.x BIOS
Press any key to display configuration menu........
Immediately press any key to interrupt the system startup.
Note: You have only 3 seconds to press any key. If you do not press a key soon enough,
the FortiGate unit reboots and you must log in and repeat the
command.
If you successfully interrupt the startup process, one of the following messages
appears:
• FortiGate unit running v2.x BIOS
Enter TFTP Server Address [192.168.1.168]:
Go to step 9.
• FortiGate unit running v3.x BIOS
[G]: Get firmware image from TFTP server.
[F]: Format boot device.
[Q]: Quit menu and continue to boot with default
firmware.
[H]: Display this list of options.
Enter G,F,Q,or H:
Testing a new firmware image before installing it
execute reboot
