Introduction

Feature

Line lifting:
Wire rope:
Brake:
Control:

Unpacking

H oist assembly..................................................................... 1 pc
. . . .
C ontrol box................................................................................ 1 pc
. . . .
R emote control ..................................................................... 1 pc
. . . .
W ire rope with hook............................................................... 1 pc
. . . .
Read this manual carefully
Carefully read and understand this manual before operating the winch.
Careless winch operation may result in personal injury, danger to others and or
damage to property
Information requesting or parts ordering
Please specify the following information:
. . . .
H oist PN
. . . .
S erial number
. . . .
Q uantity for each part
544 kg / 1,200 lb wire rope first layer
4.8 mm × 18.3m galvanized aircraft A7 × 19
Both Mechanical cone brake and permanent motor dynamic
brakes
Handheld pendant switch
Heavy Duty Hoist
Model:
. . . .
P art description
. . . .
R eplacement part number
GTD-1200
PN: 751321 12V
751375 24V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GTD-1200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Comeup GTD-1200

  • Page 1 Heavy Duty Hoist GTD-1200 Model: PN: 751321 12V 751375 24V Introduction Feature Line lifting: 544 kg / 1,200 lb wire rope first layer Wire rope: 4.8 mm × 18.3m galvanized aircraft A7 × 19 Brake: Both Mechanical cone brake and permanent motor dynamic...
  • Page 2 Installation Before using the winch ensure all electrical components are in good condition and all connections are sound. Hoist mounting . . . . F our (4) M10 x 30L 8.8 grade with 44 N-m torque settings (maximum) high tensile steel bolts must be used in order to sustain the loads imposed on the winch mounting Wire Rope Replacement ....
  • Page 3 Wiring Diagram Attach the black lead firmly to the negative (–) battery terminal and red lead to the positive (+) battery terminal. The voltage drop for the winch motor must not exceed 10% of the nominal voltage of 12/24vdc Warning T he operator shall always work in compliance with the operating instructions.
  • Page 4 Parts List Item No. Description Part No. Motor 12V 882309 Motor 24V 882310 Tie bar kit 881427 Motor support rack 882311 Motor coupling 880078 Drum bushing A 880006 Drum kit 882312 Drum bushing B 880081 Gearbox support rack 882419 shaft 881221 ring gear kit 882420...
  • Page 5 Hoist Assembly (GTD1200)
