Introduction
Feature
Line lifting:
Wire rope:
Brake:
Control:
Unpacking
．Hoist assembly..................................................................... 1 pc
．Detachable control box............................................................. 1 pc
．Remote control..................................................................... 1 pc
．Wire rope with hook............................................................... 1 pc
Read this manual carefully
You should carefully read and understand this manual before operating it.
Careless hoist operation may result in personal injury hazards or property
damage.
Information requesting or parts ordering
Please specify the following information:
． Hoist PN
． Serial number
． Quantity for each part
Installation
Before using the hoist, make sure all electrical components have no corrosion
or damaged; the environment should be clear and dry.
Attach fix plates to the foot of motor/gearbox support racks securely.
1,361 kg / 3,000 lb wire rope first layer
8.3 mm × 22.9 m (21/64" × 75') galvanized aircraft A7 × 19
Patented cone brake holds full load PLUS auxiliary inverted
current brake for a 100% & instant braking
Handheld pendant switch powers the hoist
Heavy Duty Hoist
DHC-3000
Model:
． Part description
． Replacement part number
PN: 751516 12V DC
751680 24V DC
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comeup DHC-3000
Summary of Contents for Comeup DHC-3000
- Page 1 Heavy Duty Hoist DHC-3000 Model: PN: 751516 12V DC 751680 24V DC Introduction Feature Line lifting: 1,361 kg / 3,000 lb wire rope first layer Wire rope: 8.3 mm × 22.9 m (21/64" × 75′) galvanized aircraft A7 × 19...
- Page 2 Wire Rope Replacement ．Feed the end of the wire rope into No. 1 anchor hole in the drum and wind about 1/4 wrap of rope on the drum. Insert the wire rope into No. 2 hole and tighten the set screw securely.
- Page 3 Warning ．The operator shall always work in compliance with the operating instructions. ．Overload shall be forbidden and overload protection shall be required. ． Ban on transporting persons and excessive inching shall be avoided. ．Don’t try to move obstructed loads and side-pull of load is not allowed ．...
- Page 4 Hoist Assembly...
