Mocka Kirra Six Drawer Assembly Instructions Manual

Kirra Six Drawer
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A B
dowel screw
x36
x22
G H
slide rail slide rail
x6 x6
M
long scerw small bolt
x8
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
C D
bolt small screw
locking nut
x18
x18
I
J
slide rail screw
x6 x20
N
O
small locking
x30
nut x30
Hardware Supplied
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
E
F
slide rail
x60 x6
K L
wedge scerw
x8 x8
P
long dowel
x2
V W X
safety screw wall
x2
strap x2 anchor
x2
Wall Strap
Y Z
wall washer
screw x4
x2
1
