Kirra Desk
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
B
dowel
screw
x12
x13
G
H
slide rail
slide rail
x3
x3
M
N
long scerw
nut
x6
x2
WARNING:
Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
C
D
bolt
small screw
locking nut
x30
x25
x25
I
J
slide rail
screw
wedge
x3
x16
O
P
bolt
bolt
allen key
x2
x3
Hardware Supplied
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
E
F
slide rail
x3
K
L
scerw
x4
x4
Q
x1
V
W
X
safety
screw
wall
x1
strap x1
anchor
x1
Wall Strap
Y
Z
wall
washer
screw
x2
x1
1
Advertisement
Related Manuals for Mocka Kirra
Summary of Contents for Mocka Kirra
- Page 1 Phillips & Flathead screwdrivers required. For quicker assembly, we recommend the use of a power drill on a low-speed setting. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 2 Insert 7x bolts (C) into panel [1]. Tighten with a screwdriver. Attach 3x slide rails (F) to panel [3] as shown and secure with 9x screws (E). Flip the panel [3], attach 2x bolts (C) to panel [3] as shown. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 3 Attach 3x slide rails (G) to panel [4] and secure with 9x small screws (E). Attach panels [3] and [4] to panels [5] with 4x dowels (A) and secure Tighten with a screwdriver. with 4x locking nuts (D). Tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 4 Attach panel [2] to the rest of the unit using 4x dowels (A). Attach the legs [7] to panel [2] as shown using 16x screw (J) .Tighten Secure with 6x long screws (M) and tighten with a screwdriver. with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 5 Attach panel [8] to panel [6] with 2x bolts (O) and secure with 2x nuts (N). Attach panel [6] to panel [3] with 1x dowel (A) and secure with 2x Tighten with a screwdriver. locking nuts (D). Tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 6 Attach 4x dowels (A) to panels [3] and [4] as shown. Tighten with a screwdriver. Attach panel [1] to panel [8], secure with 3x bolts (P). Tighten with an allen key (Q). mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 7 (D). Tighten with a screwdriver. Attach panels [16] and [17] to Insert 8x bolts (C) into panels [15]. Tighten with a screwdriver. panels [15] and secure with 8x locking nuts (D). Tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 8 [12]. Slide panels [13] down along the grooves between a screwdriver. Attach panels [16], [17] and [18] as shown using 8x screws (B). panels [16] and [17]. Tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 9 Attach slide rails (I) and slide rails (H) to the underside of the side panels as shown. Ensure the drawers slide easily along the rails. as shown. Secure with 12x screws (E) and tighten with a screwdriver. mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
- Page 10 1x washer (Z), 1x wall plug (X) and 1x screw (Y). Ensure unit is 1x screw (W). Tighten with a screwdriver. balanced and steady before use. You’re done, enjoy! mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558...
