  • Page 1 Buster Bubble...
  • Page 2 Table of Contents Setup - Calibration - Cleaning Page 3 - 6 Entering Setup Calibration Cleaning Touch Screen Programming Assembly diagrams Lower assembly Page 7 Monitor assembly Page 8 - 9 Back Door assembly Page 10 Bottom plate assembly Page 11 - 12 I/O board assembly Page 13 Jamma Harness Pinout...
  • Page 3 Setup Located inside the coin door are the coin and ticket meters, volume up and down buttons, service button, and test button. You can lower or raise the volume by pressing the UP and DOWN VOLUME buttons or set the volume through settings. To test play your game without adding to the coin meter, press the SERVICE but- ton.

  • Page 4: Setup - Programming

    Setup - Programming Software version 1.00.01 Main Menu Operation Adjustments Game Adjustments Default Options Invert Touch Input On/Off Use Bonus Bar Off/On Bonus Payout Amount Small Small/Medium/Large Ticket Adjustments Minimum Tickets 0 or 1 Ticket Value (in cents) 0 - 100 Credit Value (in cents) 0 - 100 Coin Settings...
  • Page 5 Setup - Programming Software version 1.00.01 Main Menu General Audits Game Audits Games played Average game time Ticket Audits Total tickets dispensed Average tickets per play Current payout percentage Total tickets (500 games) Average tickets (500 games) Payout percentage (500 games) Tickets owed System Audits Playtime...
  • Page 6 Setup - Programming Software version 1.00.01 Main Menu Reset Menu Reset game audits Reset credits Reset tickets Reset coin counters Reset adjustments Factory reset System Tests Version list Switch test Screen tests Sound test File test Coin meter test Ticket dispenser test Dipswitch settings Watchdog test Screen Calibration...
  • Page 14 COMPONENT SIDE SOLDER SIDE GROUND BLACK GROUND BLACK GROUND BLACK GROUND black + 5 VOLTS + 5 VOLTS DUMMY PIN + 5 VOLTS DUMMY PIN + 5 VOLTS DUMMY PIN DUMMY PIN DUMMY PIN + 12 VOLTS ORANGE + 12 VOLTS ORANGE COIN METER white/yellow...

  • Page 15: Parts List

    Parts List Electronics: 1029WSX Asy Reset Button BU2007X Asy (Power Mod 4 Amp) E00038 Fuse 4 Amp 250v Slow Blow E02062 Fuse 5A E02258 Fuse 2A E00211 Switch (Low Ticket) E02027FL Fan Filter BU2000X Computer DN2034x PCBA Jamma I/O Board FP2007 Speaker 4”...
  • Page 16 violet/blue TO” TICKET BLACK/black PC POWER DISPENSER violet/white ORANGE/orange E02247 PC SERIAL PORT orange TO:LOW TICKET violet/green ORANGE PC POWER BLACK COMPUTER VIOLET SUPPLY violet/green BLACK OUTPUT TO: LOW TICKET black SWITCH DN2000 PC AUDIO E00233 FP2007 5 AMP ORANGE ORANGE red/white brown/white...
  • Page 17 Contacts at SEGA Machine Sales Telephone: +44 (0) 208 391 8090 Fax: +44 (0) 208 391 8099 www.sega-amusements.co.uk SEGA Spares Telephone: +44 (0) 208 391 8060 Fax: +44 (0) 208 391 8096 www.segatotalsolutions.com Customer Services Telephone: +44 (0) 208 391 8065...
