Verifying the ReachNXT 100-8t Connection and Firmware Version

Use the show lldp neighbors detailed command to report information about the connected
ReachNXT 100-8t and its current firmware version. The firmware version is indicated on the
line, following the model name. In the following example, the firmware version 1.4.1.4 is
Description
highlighted.
X250e-24x.17 # show lldp neighbors detailed
-----------------------------------------------------------------------------
LLDP Port 25 detected 1 neighbor
Neighbor: 00:04:96:1F:A8:00/9, age 25 seconds
- Chassis ID type: MAC address (4)
Chassis ID
- Port ID type: ifName (5)
Port ID : "9"
- Time To Live: 120 seconds
- System Name: "Reach 100-8t 800284-00-01 0840G-00560"
- System Description: "Reach 100-8t 1.4.1.4"

Creating and Configuring VLANs for the ReachNXT Upgrade

If the ReachNXT 100-8t and the upgrade servers are on the same VLAN, follow the procedure in
"ReachNXT 100-8t and Upgrade Server on the Same VLAN"
upgrade servers are on different VLANs, follow the procedure in
Server on Different VLANs" on page
ReachNXT 100-8t and Upgrade Server on the Same VLAN
If the ReachNXT 100-8t and the upgrade servers are on the same VLAN, do the following to create and
configure a VLAN for the upgrade.
1 Create the VLAN and name it ReachMgmt. For example:
# create vlan ReachMgmt
NOTE
The name of the upgrade VLAN must be ReachMgmt.
2 Assign a VLAN tag to be used for the upgrade. For example:
# configure vlan ReachMgmt tag 20
3 Add each port number to which a ReachNXT 100-8t is connected. These ports must be added as
tagged ports. For example:
# configure vlan ReachMgmt add ports 25 tagged
4 Add the port to which the upgrade DHCP/BootP server and TFTP server are connected. This can be
tagged or untagged, depending on the server's capability. For example:
# configure vlan default delete ports 26
# configure vlan ReachMgmt add ports 26 untagged
5 Configure an IP address for the ReachNXT upgrade VLAN. For example:
# configure vlan ReachMgmt ipaddress 10.10.10.1 255.255.255.0
ReachNXT 100-8t User Guide
: 00:04:96:1F:A8:00
20.
Network-Based Upgrade
below. If the ReachNXT 100-8t and the
"ReachNXT 100-8t and Upgrade
System
19
