- Page 1 Manual | EN CP29xx-2xxx-0000 Control Panel 12/6/2021 | Version: 1.3...
-
Page 3: Table Of Contents
Table of contents Table of contents 1 Notes on the documentation ........................ 5 2 For your safety............................ 6 Description of safety symbols ...................... 6 Intended use ............................ 6 Fundamental safety instructions ...................... 7 Operator's obligation to exercise diligence .................. 7 Notes on information security ...................... 8 3 Product overview............................ 9 Structure ............................ 10 Interface description ........................ 11 3.2.1... - Page 4 Table of contents Version: 1.3 CP29xx-2xxx-0000...
-
Page 5: Notes On The Documentation
Copyright © Beckhoff Automation GmbH & Co. KG. Publication of this document on websites other than ours is prohibited. Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant of a patent, utility model or design. -
Page 6: For Your Safety
Exclusion of liability Beckhoff shall not be liable in the event of non-compliance with this documentation and thus the use of the devices outside the documented operating conditions. -
Page 7: Fundamental Safety Instructions
For your safety Fundamental safety instructions The following safety instructions must be observed when handling the device. Application conditions • Do not use the device under extreme environmental conditions. Protect the back of the device from dust, moisture and heat and keep the ventilation slots clear. •... -
Page 8: Notes On Information Security
For your safety Notes on information security The products of Beckhoff Automation GmbH & Co. KG (Beckhoff), insofar as they can be accessed online, are equipped with security functions that support the secure operation of plants, systems, machines and networks. Despite the security functions, the creation, implementation and constant updating of a holistic security concept for the operation are necessary to protect the respective plant, system, machine and networks against cyber threats. -
Page 9: Product Overview
Product overview Product overview The Beckhoff Panel generation with industrially-compatible multi-touch display is designed for control cabinet installation. The devices offer suitable solutions for a variety of applications. The model variety ranges from different display sizes and formats to custom models. This Panel generation is also suited for single-touch applications. -
Page 10: Structure
Product overview Structure Figure 2 shows an example of the device configuration for all CP29xx-2xxx variants. Fig. 1: CP29xx-2xxx_configuration Table 1: Legend for CP29xx-2xxx configuration Component Description Display and touch screen glass Operating the Control Panel Clamping lever Mounting the Control Panel in the control cabinet Industrial PC C6030, optional Control system in machine... -
Page 11: Interface Description
Product overview Interface description The Control Panel features the following interfaces, which are located at the back of the housing: • Power supply • USB 3.0 • DVI 3.2.1 Power supply The Control Panel is supplied with a nominal input voltage of 24 V. The five-pin power socket (X101) is used for connection to the power supply and the external wiring of the Control Panel. -
Page 12: Usb
Product overview 3.2.2 The Control Panel has a USB 3.0 interface (X104) that supports the USB 3.0 specification. The Control Panel is connected to the Industrial PC via the USB input. X104 Fig. 3: CP29xx-2xxx_USB interface pin numbering Table 3: USB interface pin assignment Assignment Shield Vbus... -
Page 13: Name Plate
Product overview Name plate The name plate is shown as an example of all versions of the Control Panel. Fig. 5: CP29xx-2xxx_Name plate example Table 5: Legend for CP29xx-2xxx name plate Description Model: The last four digits indicate the device generation. FCC approval Serial number (BTN) Date of manufacture Display... -
Page 14: Connection Cables/Connection Kits
Ready-made connection kits for DVI/USB connection are available as an option. They are included as standard when you order the C6030 as an option for mounting at the back of the Control Panel. They can also be ordered separately from Beckhoff sales, quoting the following article descriptions: Table 7: Connection kits CP29xx with C6030... -
Page 15: Commissioning
Beckhoff protective film. The film provides short-term protection for a few days. You can either order a Beckhoff protective film individually and fit it yourself retrospectively, or you can order the film for fitting directly ex works. -
Page 16: Table 9 Ordering Options: Film Fitted Ex Works
Commissioning Table 9: Ordering options: Film fitted ex works Ordering option Description C9900-T217 Adhesive protective film for Panel PCs and Control Panels with 7-inch display, for fitting onto the glass pane ex works C9900-T218 Adhesive protective film for Panel PCs and Control Panels with 12-inch display, for fitting onto the glass pane ex works C9900-T237 Adhesive protective film for Panel PCs and Control Panels with 12.1-inch display, for... -
Page 17: Transport And Unpacking
5. Check the contents for visible shipping damage. 6. In case of discrepancies between the package contents and the order, or in case of transport damage, please inform Beckhoff Service (see Chapter 9.1 Service and support [} 32]). CP29xx-2xxx-0000 Version: 1.3... -
Page 18: Installation In The Control Cabinet
Commissioning Installation in the control cabinet The CP29xx-2xxx Control Panel is designed for installation in control cabinets for machine and plant technology. Please observe the environmental conditions prescribed for the operation (see Chapter 8 Technical Data [} 31]). The C6030 Industrial PC can optionally me mounted at the back of the Control Panel. If you choose this option, you must first install the C6030 before you can mount the Control Panel in the control cabinet. -
Page 19: Fig. 8 Cp29Xx-2Xxx_Dimensions, 19 Inches
Commissioning 51,5 cut-out dimensions: 1,5 - 2,5 Fig. 8: CP29xx-2xxx_dimensions, 19 inches Fig. 9 shows the dimensions of the Control Panel with 21.5 inch display. 51,5 cut-out dimensions: 1,5-2,5 Fig. 9: CP29xx-2xxx_dimensions, 21.5 inches CP29xx-2xxx-0000 Version: 1.3... -
Page 20: C6030 Installation
Commissioning 4.2.2 C6030 installation A C6030 can optionally be mounted at the back of the Control Panel. The following section contains the information required for installing the Industrial PC. The following two ordering options are available for the C6030 Industrial PC: •... - Page 21 Commissioning For more information about the C6030 Industrial PC please refer to the device documentation. CP29xx-2xxx-0000 Version: 1.3...
-
Page 22: Installation In The Control Cabinet
Commissioning 4.2.3 Installation in the control cabinet Preparation of the control cabinet The control cabinet must have the required installation cutout according to the device dimensions (see Chapter 4.2.1 Dimensions [} 18]) of the Control Panel. NOTE Extreme environmental conditions Extreme environmental conditions can cause damage to the device. •... -
Page 23: Installing The Supply Cable
It consists of a 5-pin connection strip and a strain relief housing with cable tie. If you require a replacement for the voltage connector or the strain relief housing, you can order these from Beckhoff Sales using the following ordering option: • C9900-P927: Power supply connector for multi-touch built-in Control Panel CP29xx, 5-pin connector... -
Page 24: Fig. 14 Cp29Xx_Disassembly The Strain Relief Housing
Commissioning Fig. 14: CP29xx_Disassembly the strain relief housing Version: 1.3 CP29xx-2xxx-0000... -
Page 25: Grounding The Control Panel
Commissioning 4.3.2 Grounding the Control Panel Potential differences are minimized and electrical currents are diverted to the ground through grounding or potential equalization of electronic devices. This is to prevent dangerous touch voltages and electromagnetic interference. Protective earth Establish low-resistance protective earth of the Control Panel via the voltage connection to avoid dangerous touch voltages. -
Page 26: Connecting Cables And Power Supply
Commissioning 4.3.3 Connecting cables and power supply NOTE Incorrect connection procedure Incorrect procedure when connecting the cables and the power supply can cause hardware damage. • Follow the documented procedure for connecting the cables and the power supply. • Always connect all cables first and only then switch on the power supply. •... -
Page 27: Shutting Down
Shutting down Shutting down NOTE Hardware damage due to power supply A connected power supply can cause damage to the Control Panel during disassembly. • Disconnect the power supply from the device before starting to disassemble it. When taking the Control Panel out of operation, you must first disconnect the power supply and cables. You can then remove the device from the control cabinet. -
Page 28: Disassembly And Disposal
Shutting down Disassembly and disposal Removal from the control cabinet Before you can remove the Control Panel from the control cabinet, you must first disconnect the power supply and the cables (see Chapter 5.1 Disconnecting the power supply and cables [} 27]). To remove the Control Panel from the control cabinet, follow the steps shown in Fig. -
Page 29: Servicing And Maintenance
• Cold water with a heated unit • High water pressure, e.g. high-pressure cleaner Repair Only the manufacturer may repair the device. If a repair should be necessary, contact Beckhoff Service (see Chapter 9.1 Service and support [} 32]). CP29xx-2xxx-0000 Version: 1.3... -
Page 30: Troubleshooting
Problem with the cable connections CP29xx-0000: Check the DVI cable connection CP29xx-0010: 1. Check the cable connec- tions 2. Check the CU880x diagnos- tic LEDs 3. Check the power supply Beckhoff recommends using Beckhoff connection cables and connection kits. Version: 1.3 CP29xx-2xxx-0000... -
Page 31: Technical Data
Technical Data Technical Data Table 11: Technical data Product designation CP29xx-2xxx Dimensions (W x H x D) CP2916: 432 x 302 x 61 mm CP2918: 498 x 341 x 59 mm CP2919: 463 x 393 x 59 mm CP2921: 569 x 377 x 59 mm Weight CP2916: approx. -
Page 32: Appendix
Phone: + 49 (0) 5246/963-0 Fax: + 49 (0) 5246/963-198 e-mail: info@beckhoff.de The addresses of the worldwide Beckhoff branch offices and agencies can be found on our website at http:// www.beckhoff.com/. You will also find further documentation for Beckhoff components there. -
Page 33: Approvals
Appendix Approvals The Control Panel is CE certified. FCC approvals for the United States of America FCC: Federal Communications Commission Radio Frequency Interference Statement This device was tested and complies with the limits for a digital device of class A, according part 15 of the FCC regulations. - Page 34 List of figures List of figures Fig. 1 CP29xx-2xxx_configuration ......................Fig. 2 CP29xx-2xxx_Voltage connector pin numbering................. Fig. 3 CP29xx-2xxx_USB interface pin numbering................Fig. 4 CP29xx_DVI interface pin numbering..................Fig. 5 CP29xx-2xxx_Name plate example..................... Fig. 6 CP29xx-2xxx_dimensions, 15.6 inches ..................Fig. 7 CP29xx-2xxx_dimensions, 18.5 inches ..................
- Page 35 List of tables List of tables Table 1 Legend for CP29xx-2xxx configuration..................Table 2 Voltage connector pin assignment....................Table 3 USB interface pin assignment ..................... Table 4 DVI interface pin numbering ......................Table 5 Legend for CP29xx-2xxx name plate................... Table 6 Connection cables/kits CP29xx ....................Table 7 Connection kits CP29xx with C6030....................
- Page 37 Beckhoff Automation GmbH & Co. KG Hülshorstweg 20 33415 Verl Germany Phone: +49 5246 9630 info@beckhoff.com www.beckhoff.com...
