Instruction Sheet
MK Series
Assembly Instructions
THANK YOU
Thank you for purchasing the MK Series. Please read these instructions
thoroughly before installing / assembling this product.
PRODUCT FEATURES
- Cable pass-throughs
- 24" base width for use with raised flooring tiles
I-2220
Rev F
Advertisement
Table of Contents
Related Manuals for Middle Atlantic Products MK Series
Summary of Contents for Middle Atlantic Products MK Series
- Page 1 Instruction Sheet MK Series Assembly Instructions THANK YOU Thank you for purchasing the MK Series. Please read these instructions thoroughly before installing / assembling this product. PRODUCT FEATURES - Cable pass-throughs - 24” base width for use with raised flooring tiles...
- Page 2 ASSEMBLY NOTE: The provided acorn nuts should be installed after the flange nuts to protect the wires from damage 1) Install the bases to channels. FLANGE NUT LARGE ACORN 2) Install the top angles to the channels. FLANGE NUT LARGE ACORN Page 2...
- Page 3 3) Install the cable bridges to the top angles. INSTALL INCLUDED HOLE PLUGS AT LABELED DESIRED "REAR" LOCATIONS HOOK AND LOOP FASTENERS ARE PROVIDED FOR MANAGING INTERNAL CABLES LABELED "REAR" 4) Mount the cable management rings at the angle required. SMALL ACORN NUT POSITION AS DESIRED Page 3...
- Page 4 WARRANTY Middle Atlantic Products (the "Company") warrants the MK Series to be free from defects in material or workmanship under normal use and conditions for the lifetime of the product. The Company's entire liability to the purchaser, and the purchaser's (or any other party's) sole and...
